U7 Pro XGS | PrisHundenArt.nr: U7-Pro-XGS-B-US · P/N: U7-Pro-XGS-B-US
- WiFi
- WiFi 7
- Vikt
- 0.8 kg
- 5 GHz
- Ja
- 6 GHz
- Ja
- Ethernet
- 10 Gbps
- LAN-portar
- 1
- Mounting
- Ceiling, Wall / (Lite Mount Included)
- 2,4 GHz
- Ja
- Mesh-stöd
- Mesh
- Strömförsörjning
- PoE++
- Täckningsyta
- 160 m²
- Max klienter
- 500
- Spatial streams
- 8
Övriga specifikationer
- Uplink
- 10 GbE
- Dimensions
- ⌀215 x 32.5 mm / (⌀8.5 x 1.3")
- MIMO 5 GHz
- 4 x 4 (DL/UL MU-MIMO)
- MIMO 6 GHz
- 2 x 2 (DL/UL MU-MIMO)
- Management
- Ethernet
- LEDs System
- White/Blue
- Max. BSSIDs
- 8 per Radio
- MIMO 2.4 GHz
- 2 x 2 (DL/UL MU-MIMO)
- Band Steering
- Ja
- WiFi Standard
- WiFi 7
- Zero-Wait DFS
- Ja
- Certifications
- CE, FCC, IC, Anatel: 05123-25-08356
Priser hos återförsäljare
| Butik | Logotyp | Pris | Lager | |
|---|
| Inga aktuella priser tillgängliga. |
Recensioner
Laddar recensioner…
Channel BandwidthHT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz) Enclosure MaterialUV-stabilized polycarbonate, aluminum alloy Max. TX Power 5 GHz29 dBm Max. TX Power 6 GHz24 dBm Operating FrequencyUS/CA: / 2400 - 2472 MHz / U-NII-1: 5150 - 5250 MHz / U-NII-2A: 5250 - 5350 MHz / U-NII-2C: 5470 - 5725 MHz / U-NII-3: 5725 - 5850 MHz / U-NII-5 to U-NII-8: 5925 - 7125 MHz / Worldwide: / 2400 - 2483.5 MHz / 5150 - 5850 MHz / 5925 - 7125 MHz Antenna Gain 2.4 GHz4 dBi Max. Data Rate 5 GHz8.6 Gbps (BW240) Max. Data Rate 6 GHz5.8 Gbps (BW320) Networking Interface(1) 10 GbE RJ45 port Max. TX Power 2.4 GHz23 dBm Max. Data Rate 2.4 GHz688 Mbps (BW40) Max. Power Consumption29W Client Device IsolationJa Passpoint (Hotspot 2.0)Ja Supported Voltage Range42.5–57V DC RADIUS over TLS (RadSec)Ja Advanced Radio ManagementJa Ambient Operating Humidity5 to 95% noncondensing Real-Time Spectral AnalysisJa Dynamic RADIUS-assigned VLANJa Supported Data Rates 802.11n6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) Ambient Operating Temperature-30 to 40° C (-22 to 104° F) Private Pre-Shared Key (PPSK)Ja 802.11v BSS Transition ManagementJa Application Requirements UniFi NetworkVersion 9.0.114 and later (U7 Pro XGS - White) / Version 9.1.120 and later (U7 Pro XGS - Black) Supported Data Rates 802.11ac (WiFi 5)6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) Supported Data Rates 802.11ax (WiFi 6)7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) Supported Data Rates 802.11be (WiFi 7)6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320) / 5 GHz: 7.3 Mbps to 8.6 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240) 802.11k Radio Resource Management (RRM)Ja Captive Hotspot Portal Voucher AuthenticationJa Captive Hotspot Portal Guest Network IsolationJa Captive Hotspot Portal Password AuthenticationJa Captive Hotspot Portal Custom Branding Landing PageJa Captive Hotspot Portal Payment-Based AuthenticationJa Captive Hotspot Portal External Portal Server SupportJa
