WiFi

WiFi 7

Vikt

0.75 kg

5 GHz

Ja

6 GHz

Ja

Ethernet

10 Gbps

LAN-portar

1

Mounting

Ceiling, Wall / (Lite Mount Included)

2,4 GHz

Ja

Mesh-stöd

Mesh

Power Method

PoE+

Coverage Area M2

140 m²

Max Client Count

300

Spatial Streams

6

Övriga specifikationer

Uplink

10 GbE

Dimensions

⌀206 x 32.5 mm / (⌀8.1 x 1.3")

MIMO 5 GHz

2 x 2 (DL/UL MU-MIMO)

MIMO 6 GHz

2 x 2 (DL/UL MU-MIMO)

Management

Ethernet

LEDs System

White/Blue

Max. BSSIDs

8 per Radio

MIMO 2.4 GHz

2 x 2 (DL/UL MU-MIMO)

Band Steering

Ja

WiFi Standard

WiFi 7

Certifications

CE, FCC, IC, Anatel: 06630-25-08356

Mount Material

Stainless steel (SUS304), galvanized steel (SGCC)

NDAA Compliant

Ja

WiFi Schedules

Ja

Wireless Meshing

Ja

Channel Bandwidth

HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)

Antenna Gain 5 GHz

5 dBi

Antenna Gain 6 GHz

6 dBi

Enclosure Material

UV-stabilized polycarbonate, aluminum alloy

Max. TX Power 5 GHz

26 dBm

Max. TX Power 6 GHz

24 dBm

Operating Frequency

US/CA: / 2400 - 2472 MHz / U-NII-1: 5150 - 5250 MHz / U-NII-2A: 5250 - 5350 MHz / U-NII-2C: 5470 - 5725 MHz / U-NII-3: 5725 - 5850 MHz / U-NII-5 to U-NII-8: 5925 - 7125 MHz / Worldwide: / 2400 - 2483.5 MHz / 5150 - 5850 MHz / 5925 - 7125 MHz

WiFi Speed Limiting

Ja

802.11r Fast Roaming

Ja

Antenna Gain 2.4 GHz

4 dBi

Max. Data Rate 5 GHz

4.3 Gbps (BW240)

Max. Data Rate 6 GHz

5.8 Gbps (BW320)

Networking Interface

(1) 10 GbE RJ45 port

Max. TX Power 2.4 GHz

23 dBm

Max. Data Rate 2.4 GHz

688 Mbps (BW40)

Max. Power Consumption

22W

Client Device Isolation

Ja

Passpoint (Hotspot 2.0)

Ja

Supported Voltage Range

42.5–57V DC

RADIUS over TLS (RadSec)

Ja

Advanced Radio Management

Ja

Ambient Operating Humidity

5 to 95% noncondensing

Dynamic RADIUS-assigned VLAN

Ja

Supported Data Rates 802.11n

6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Ambient Operating Temperature

-30 to 40° C (-22 to 104° F)

Private Pre-Shared Key (PPSK)

Ja

802.11v BSS Transition Management

Ja

Application Requirements UniFi Network

Version 9.0.114 and later (U7 Pro XG - White) / Version 9.1.120 and later (U7 Pro XG - Black)

Supported Data Rates 802.11ac (WiFi 5)

6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)

Supported Data Rates 802.11ax (WiFi 6)

7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)

Supported Data Rates 802.11be (WiFi 7)

6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320) / 5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)

802.11k Radio Resource Management (RRM)

Ja

Captive Hotspot Portal Voucher Authentication

Ja

Captive Hotspot Portal Guest Network Isolation

Ja

Captive Hotspot Portal Password Authentication

Ja

Captive Hotspot Portal Custom Branding Landing Page

Ja

Captive Hotspot Portal Payment-Based Authentication

Ja

Captive Hotspot Portal External Portal Server Support

Ja
