WiFi

WiFi 7

Vikt

0.313 kg

5 GHz

Ja

6 GHz

Nej

Ethernet

2.5 Gbps

LAN-portar

1

Mounting

Ceiling, Wall / (Lite Mount Included)

2,4 GHz

Ja

Mesh-stöd

Mesh

Power Method

PoE

Coverage Area M2

115 m²

Max Client Count

200

Spatial Streams

4

Övriga specifikationer

Uplink

2.5 GbE

Dimensions

⌀171.5 x 33 mm / (⌀6.8 x 1.3")

MIMO 5 GHz

2 x 2 (DL/UL MU-MIMO)

Management

Ethernet

LEDs System

White/Blue

Max. BSSIDs

8 per Radio

MIMO 2.4 GHz

2 x 2 (DL/UL MU-MIMO)

Band Steering

Ja

WiFi Standard

WIFi 7

Certifications

CE, FCC, IC, SRRC, Anatel: 02143-25-08356

Mount Material

UV-stabilized polycarbonate, galvanized steel (SGCC)

NDAA Compliant

Ja

WiFi Schedules

Ja

Wireless Meshing

Ja

Channel Bandwidth

HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz)

Antenna Gain 5 GHz

5 dBi

Enclosure Material

UV-stabilized polycarbonate

Max. TX Power 5 GHz

24 dBm

WiFi Speed Limiting

Ja

802.11r Fast Roaming

Ja

Antenna Gain 2.4 GHz

4 dBi

Max. Data Rate 5 GHz

4.3 Gbps (BW240)

Networking Interface

(1) 2.5 GbE RJ45 port

Max. TX Power 2.4 GHz

23 dBm

Max. Data Rate 2.4 GHz

688 Mbps (BW40)

Max. Power Consumption

13W

Client Device Isolation

Ja

Passpoint (Hotspot 2.0)

Ja

Supported Voltage Range

42.5–57V DC

RADIUS over TLS (RadSec)

Ja

Advanced Radio Management

Ja

Ambient Operating Humidity

5 to 95% noncondensing

Dynamic RADIUS-assigned VLAN

Ja

Supported Data Rates 802.11n

6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Ambient Operating Temperature

-30 to 40° C (-22 to 104° F)

Private Pre-Shared Key (PPSK)

Ja

802.11v BSS Transition Management

Ja

Application Requirements Mobile App

iOS version 10.20.2 and later / Android version 10.21.7 and later

Application Requirements UniFi Network

Version 9.0.114 and later

Supported Data Rates 802.11ac (WiFi 5)

6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)

Supported Data Rates 802.11ax (WiFi 6)

7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)

Supported Data Rates 802.11be (WiFi 7)

7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)

802.11k Radio Resource Management (RRM)

Ja

Captive Hotspot Portal Voucher Authentication

Ja

Captive Hotspot Portal Guest Network Isolation

Ja

Captive Hotspot Portal Password Authentication

Ja

Captive Hotspot Portal Custom Branding Landing Page

Ja

Captive Hotspot Portal Payment-Based Authentication

Ja

Captive Hotspot Portal External Portal Server Support

Ja
