VPN

Ja

VLAN

Ja

SD-WAN

Ja

Ethernet

10 Gbps

LAN-portar

3

SFP-portar

1

WAN-portar

3

Lastbalansering

Ja

Ids Ips Throughput

5000 Mbps

Övriga specifikationer

Button

(1) Factory reset / (2) Handle release buttons

Weight

Device: 2.4 kg (5.3 lb) / Table stand: 321 g (11.3 oz)

LEDs SIM

Ja

LEDs SFP+

Ja

Processor

Quad-core ARM Cortex-A73 at 2.2 GHz

Dimensions

Device: 307.9 x 203.5 x 43.7 mm / (12.1 x 8 x 1.7") / Table stand: 203.5 x 100.2 x 21.9 mm / (8 x 3.9 x 0.9")

MIMO 5 GHz

2 x 2 (DL/UL MU-MIMO)

Management

Ethernet / Bluetooth

PoE Budget

DC input: 270W / ATX power: 75W

Ad Blocking

Ja

Form Factor

Wall-mounted / Compact desktop (Table stand included) / Rack mount (Accessory sold separately)

LEDs System

Ja

NVR Storage

Pre-installed 128 GB microSD for NVR

Advanced QoS

Ja

LEDs MicroSD

Ja

MIMO 2.4 GHz

2 x 2 (DL/UL MU-MIMO)

Power Method

(1) DC Input (350W PSU) / (1) ATX power (48V)

Power Supply

54V DC, 350W (Adapter included) / ATX power (48V)

Coverage Area

115 m² (1,250 ft²)

LEDs Ethernet

Ja

System Memory

3 GB

WiFi Standard

802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7)

Certifications

CE, FCC, IC

Expansion Slot

MicroSD Card

NDAA Compliant

Ja

Managed Cameras

(15) HD / (8) 2K / (5) 4K

VPN Server L2TP

Ja

Heat Dissipation

95 BTU/hr (Excluding PoE output)

Throughput 5 GHz

4.3 Gbps

Content Filtering

Ja

Default WAN Ports

(1) 10G SFP+ / (1) 10 GbE RJ45 / (1) 2.5 GbE RJ45

Stateful Firewall

Ja

Antenna Gain 5 GHz

Stub antenna: 5 dBi / Terminal (Omni) antenna: 6 dBi

ESD/EMP Protection

Air: ± 8kV, contact: ± 4kV

Enclosure Material

Device: Polycarbonate, aluminium alloy / Table stand: Polycarbonate, galvanized steel, silicone rubber

IDS/IPS Signatures

55,000+ with CyberSecure

Throughput 2.4 GHz

688 Mbps

VPN Client OpenVPN

Ja

VPN Server OpenVPN

Ja

License-Free SD-WAN

Ja

Managed Access Hubs

50

Max. TX Power 5 GHz

26 dBm

Max. WAN Port Count

5

Antenna Gain 2.4 GHz

Stub antenna: 3 dBi / Terminal (Omni) antenna: 6 dBi

Dynamic Routing OSPF

Ja

Multicast DNS (mDNS)

Ja

Port Layout 10G SFP+

1 / (10G/1G)

VPN Client WireGuard

Ja

VPN Server WireGuard

Ja

Managed UniFi Devices

50+

Max. TX Power 2.4 GHz

23 dBm

MAC Address Table Size

4,000

Max. Power Consumption

28W (Excluding PoE output)

Site-to-Site VPN IPsec

Ja

Voltage Range PoE Mode

50-57V

Port Layout 10 GbE RJ45

1 (PoE+++) / (10G/5G/2.5G/1G/100M)

Supported Voltage Range

100–240V AC

Integrated RADIUS Server

Ja

Multi-WAN Load Balancing

Ja

Port Layout 2.5 GbE RJ45

4 (2 PoE+++, 2 PoE+) / (2.5G/1G/100M)

RADIUS over TLS (RadSec)

Ja

Site-to-Site VPN OpenVPN

Ja

Virtual Network Override

Ja

Ambient Operating Humidity

5 to 95% noncondensing

Site-to-Site VPN Site Magic

Ja

DPI & Traffic Identification

Ja

Simultaneous Users Connected

500+

Supported Data Rates 802.11a

6, 9, 12, 18, 24, 36, 48, 54 Mbps

Supported Data Rates 802.11b

1, 2, 5.5, 11 Mbps

Supported Data Rates 802.11g

6, 9, 12, 18, 24, 36, 48, 54 Mbps

Supported Data Rates 802.11n

6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

UniFi Application Suite Talk

Ja

Ambient Operating Temperature

-30 to 50° C (-22 to 122° F)

Intrusion Prevention (IPS/IDS)

Ja

UniFi Application Suite Access

Ja

UniFi Application Suite Connect

Ja

UniFi Application Suite Network

Ja

UniFi Application Suite Protect

Ja

Application-Aware Layer 7 Firewall

Ja

Application Requirements Mobile App

UniFi iOS: Version 10.32.0 and later / UniFi Android: Version 10.35.0 and later

Internet Quality and Outage Reporting

Ja

Max. PoE Wattage per Port by PSE PoE+

30W

Supported Data Rates 802.11ac (WiFi 5)

6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)

Supported Data Rates 802.11ax (WiFi 6)

7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)

Supported Data Rates 802.11be (WiFi 7)

7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)

VLAN/Subnet-based Traffic Segmentation

Ja

Max. PoE Wattage per Port by PSE PoE+++

90W

VPN Server Identity Endpoint One-Click VPN

Ja

VPN Server Teleport Zero-Configuration VPN

Ja

Additional Internet Failover with UniFi LTE Backup

Ja

Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)

Ja

Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)

Ja
