WiFi

WiFi 5

Vikt

0.376 kg

5 GHz

Ja

6 GHz

Nej

Ethernet

1 Gbps

LAN-portar

1

2,4 GHz

Ja

Power Method

PoE

Spatial Streams

2

Väderklassning

IPX6

Övriga specifikationer

Button

(1) Factory reset

Dimensions

⌀140 x 90 mm / (⌀5.5 x 3.5")

MIMO 5 GHz

2 x 2 (DL MU-MIMO)

Management

Ethernet / Bluetooth

LEDs System

R/G/B

Wind Loading

56 N at 200 km/h (12.6 lbf at 125 mph)

WiFi Standard

WiFi 5

Certifications

CE, FCC, IC

NDAA Compliant

Ja

Bluetooth (MHz)

Worldwide: 2400 - 2483.5 MHz

Operating Modes

PtP

Channel Bandwidth

Main radio (60 GHz): 1,080/2,160 MHz / Backup radio (5 GHz): HT 20/40 MHz, VHT 20/40/80 MHz

Wireless Security

WPA2 AES

Antenna Gain 5 GHz

10 dBi

Enclosure Material

UV-resistant polycarbonate

Mounting Locations

Wall, pole

Antenna Gain 60 GHz

17.2 dBi

Max. TX Power 5 GHz

25 dBm

Operating Frequency

Main radio (60 GHz): 57 - 66 GHz / Backup radio (5 GHz): / US/CA / U-NII-1: 5150 - 5250 MHz / U-NII-2A: 5250 - 5350 MHz / U-NII-2C: 5470 - 5725 MHz / U-NII-3: 5725 - 5850 MHz / Worldwide / 5150 - 5850 MHz

Antenna Gain 2.4 GHz

2 dBi (BLE)

Includes PoE Adapter

Ja

Max. Data Rate 5 GHz

866.6 Mbps (BW80)

Max. TX Power 60 GHz

19 dBm

Networking Interface

(1) GbE RJ45 port

Max. Data Rate 60 GHz

1.7 Gbps

Max. Power Consumption

11W

Supported Voltage Range

44–57V DC

Ambient Operating Humidity

5 to 95% noncondensing

Supported Data Rates 802.11a

6, 9, 12, 18, 24, 36, 48, 54 Mbps

Supported Data Rates 802.11b

1, 2, 5.5, 11 Mbps

Supported Data Rates 802.11g

6, 9, 12, 18, 24, 36, 48, 54 Mbps

Supported Data Rates 802.11n

6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Ambient Operating Temperature

-40 to 70° C (-40 to 158° F)

Supported Data Rates 802.11ac (WiFi 5)

6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
