Vikt

16.62 kg

Front I/O

USB Type-C x 1, USB 3.0 x 2, SPK x 1, MIC x1

Material

Plastic front panel, Galvanized steel body

Dimensioner

453 × 175 × 683 mm

Formfaktor

SSI-EEB, SSI-CEB, E-ATX, ATX, Micro-ATX, Mini-ITX

Max 120 mm-fläktar

3

Max 140 mm-fläktar

0

2.5"-fack

2

3.5"-fack

2

Medföljande fläktar

80mm x 2 (8038 x 2 black fans included), 120mm x 3 (12025 x 3 black fans included)

Max GPU-längd

370 mm

Expansionsplatser

8

Max kylarhöjd

145 mm

Övriga specifikationer

Extra

* The internal USB 3 Type-C cable is 800mm in length. If you plan to connect external storage devices, please avoid using excessively long external cables to prevent potential speed reduction.

Drive bay

External: 2.5” / 3.5” SAS / SATA external hot-swapping x 8 | 5.25" x 2 | 3.5" x 1

Model No.

SST-WS380-E

Power supply

PS2 (ATX) / 2U Redundant

Front buttons

Power On / Off, system reset

HDD backplane

backplane: 8 ports SAS / SATA to Mini-SAS HD SFF-8643 x 2 with SGPIO | power connector: 4-Pin peripheral x 2 | interface: SAS-1 / SAS-2 / SAS-3 | SATA-1 / SATA-2 / SATA-3

Cooling system

Rear: 80mm x 2 (8038 x 2 black fans included) | Internal: 120mm x 3 (12025 x 3 black fans included)

LED Indicators

Chassis: Power LED x 1: Green | HDD Access x 1: White | LAN LED x 2: Green | UID x 1:White | Sys Error : Red | HDD Tray: HDD Power LED : Green | HDD Access : Blue blinking

Radiator support

Internal: 120mm / 240mm / 360mm

Drive bay External

2.5” / 3.5” SAS / SATA external hot-swapping x 8 | 5.25" x 2 | 3.5" x 1

Cooling system Rear

80mm x 2 (8038 x 2 black fans included)

Main metal thickness

1.0~1.2mm

LED Indicators Chassis

Power LED x 1: Green | HDD Access x 1: White | LAN LED x 2: Green | UID x 1:White | Sys Error : Red

Cooling system Internal

120mm x 3 (12025 x 3 black fans included)

HDD backplane backplane

8 ports SAS / SATA to Mini-SAS HD SFF-8643 x 2 with SGPIO

HDD backplane interface

SAS-1 / SAS-2 / SAS-3 | SATA-1 / SATA-2 / SATA-3

LED Indicators HDD Tray

HDD Power LED : Green | HDD Access : Blue blinking

Radiator support Internal

120mm / 240mm / 360mm

Limitation of expansion card

Length: 370mm | Width: 150mm

HDD backplane power connector

4-Pin peripheral x 2

Limitation of expansion card Width

150mm
