Typ

Air

Ljudnivå

30.9 dBA

Vikt

0.191 kg

Luftflöde

35.9 m3/h

Fläktstorlek

40 mm

Antal fläktar

1

Fläkthastighet

800~3400rpm

Material

Aluminum extruded fins

TDP-kapacitet

80 W

Dimensioner

68 × 40 × 77 mm

Lagertyp

Dual Ball Bearing

Statiskt tryck

2.32 mmH2O

Sockelkompatibilitet

AMD Socket AM5, AM4

Övriga specifikationer

Fan

Dimension: 70mm (W) x 15mm (H) x 70mm (D) | Speed: 800~3400rpm | Noise level: 30.9 dBA | Rated Voltage: 12V | Rated Current: 0.13A | Max airflow: 21.11 CFM | Max air pressure: 2.32 mmH2O | Connector: 4pin PWM | Bearing: Dual Ball Bearing | MTTF: 70,000 hours

Remark

* Requires the AMD-standard backplate on the motherboard

Fan MTTF

70,000 hours

Model No.

SST-NT09-AM5

Fan Connector

4pin PWM

Fan Rated Current

0.13A

Fan Rated Voltage

12V
