Lucid 05

Djup

17 mm

Bredd

9 mm

Höjd

19 mm

Volym

0 L

Front I/O

USB-C x 1, USB 3.x Type-A x 2, Microphone x 1, Audio x 1

Material

Metal, Plastic, Glass

Dimensioner

220 491.5 427.6 mm

Formfaktor

Mini-ITX, Micro-ATX, ATX

Max 120 mm-fläktar

9

Max 140 mm-fläktar

2

2.5"-fack

3

3.5"-fack

3

Medföljande fläktar

120mm x 1, (120mm x 1 ARGB fan included), 120mm x 3 / 140mm x 2, Motherboard Tray:120mm x 2(120mm x 2 ARGB fans included), PSU Shroud:Top:120mm x 3, Front:80mm x 2

Max GPU-längd

410 mm

Max PSU-längd

200 mm

Sidopanel

Tempered Glass

Expansionsplatser

7

Max kylarhöjd

173 mm

Övriga specifikationer

Remark

[1] When installing two 2.5" SSDs in this position, ensure the connectors face the rear to prevent interference. | [2] When mounting a 360mm radiator in this position, ensure the inlet and outlet tubes are orientated toward the front to prevent interference. | [3] When mounting a 240mm radiator in this position, graphics card clearance is limited to 281mm, including power connectors. Ensure the fans are installed between the radiator and motherboard tray to accommodate this restriction.

Drive bay

Internal: 3.5" x 1 / 2.5" x 1 / 2.5" x 2 [1] | 3.5" x 1 | 2.5" x 1

Model No.

SST-LD05-B-ARGB (Black) | SST-LD05-W-ARGB (White)

Power supply

Standard PS2 (ATX)

Cooling system

Rear: 120mm x 1 | (120mm x 1 ARGB fan included) | Top: 120mm x 3 / 140mm x 2 | Internal: Motherboard Tray:120mm x 2(120mm x 2 ARGB fans included) | PSU Shroud:Top:120mm x 3 | Front:80mm x 2

Radiator support

Rear: 120mm | Top: 120mm / 140mm / 240mm / 280mm / 360mm[2] | Internal: Motherboard Tray:240mm[3]

Cooling system Top

120mm x 3 / 140mm x 2

Drive bay Internal

3.5" x 1 / 2.5" x 1 / 2.5" x 2 [1] | 3.5" x 1 | 2.5" x 1

Cooling system Rear

120mm x 1 | (120mm x 1 ARGB fan included)
