Vikt

21.3 kg

Front I/O

USB Type-C x 1, USB 3.0 x 2

Material

Steel, aluminum

Dimensioner

265 × 651 × 457 mm

Formfaktor

Specialized form factor (15.12" x 13.2"), SSI-EEB (12" x 13"), SSI-CEB (12" x 10.5"), Extended ATX (12" x 13"), XL-ATX(13.5" x 10.3"), ATX (12" x 9.6"), Micro-ATX (9.6" x 9.6"), Mini-ITX (6.7" x 6.7")

Max 120 mm-fläktar

13

Max 140 mm-fläktar

9

2.5"-fack

5

3.5"-fack

5

Medföljande fläktar

180mm x 2 + 160mm x 1 or 140mm x 1 / 80mm x 8 + 140mm x 1, (180mm x 2 black fans included), 120mm x 1 / 140mm x 1 (140mm x 1 black fan included), 120mm x 3 (without modular kit occupied), Left side : 120mm x 6 / 140mm x 4 [2], Right side : 120mm x 3 / 140mm x 2 [2]

Max GPU-längd

407 mm

Expansionsplatser

11

Max kylarhöjd

191 mm

Övriga specifikationer

Remark

[1] Two drive cages are included, with a maximum of six cages that can be mounted inside the chassis. Additional cages can be purchased separately. | [2] Mounted on a fan/radiator bracket, with one bracket pre-installed on the left and right side of the chassis respectively, each bracket supports either 120mm x 3 or 140mm x 2 fans. The bracket on the right side can be removed to be mounted on the left side as per requirement. Additional brackets can be purchased separately

Drive bay

External: (5.25" x 2 / 3.5" x 2 / 2.5" x 4) x 2 [1]

Model No.

SST-ALD1B

Power supply

Standard PS2 (ATX) + Standard PS2 (ATX)

Cooling system

Front: 180mm x 2 + 160mm x 1 or 140mm x 1 / 80mm x 8 + 140mm x 1 | (180mm x 2 black fans included) | Rear: 120mm x 1 / 140mm x 1 (140mm x 1 black fan included) | Bottom: 120mm x 3 (without modular kit occupied) | Side: Left side : 120mm x 6 / 140mm x 4 [2] | Right side : 120mm x 3 / 140mm x 2 [2]

Radiator support

Rear: 120mm | Bottom: 120mm / 240mm / 360mm (without modular kit occupied) | Side: Left side : (120mm / 140mm / 240mm / 280mm / 360mm) x 2 [2] | Right side : 120mm / 140mm / 240mm / 280mm / 360mm [2]

Drive bay External

(5.25" x 2 / 3.5" x 2 / 2.5" x 4) x 2 [1]

Cooling system Rear

120mm x 1 / 140mm x 1 (140mm x 1 black fan included)

Cooling system Side

Left side : 120mm x 6 / 140mm x 4 [2] | Right side : 120mm x 3 / 140mm x 2 [2]

Cooling system Front

180mm x 2 + 160mm x 1 or 140mm x 1 / 80mm x 8 + 140mm x 1 | (180mm x 2 black fans included)

Cooling system Bottom

120mm x 3 (without modular kit occupied)

Radiator support Rear

120mm

Radiator support Side

Left side : (120mm / 140mm / 240mm / 280mm / 360mm) x 2 [2] | Right side : 120mm / 140mm / 240mm / 280mm / 360mm [2]

Radiator support Bottom

120mm / 240mm / 360mm (without modular kit occupied)
