TDP

285 W

Basklocka

1965 MHz

CUDA-kärnor

2560

Minnesbuss

256-bit

Boost-klocka

2035 MHz

Minne

8 GB

Minnestyp

GDDR6

Max antal skärmar

4

Minneshastighet

14.4 Gbps

Buss

PCIe 4.0 x16

Max upplösning

HDMI: 4096×2160@60Hz DisplayPort1.4: 5120×2880@60Hz

Displayutgångar

2x HDMI 2x DisplayPort

Övriga specifikationer

OS

Linux, Windows 11, 10, Windows 7 64bit operating system required

API

Vulkan OpenGL 4.6 OpenCL 2.0 DirectX 12 Shader Model 6.4

Game Index

Extreme 1440P

Cooler Type

Tri-X Cooling Triple Fan Two-Ball Bearing

Form Factor

2.5 slot, ATX Dimension: 306x 135 x 49 (mm)

AMD Features

RDNA Architecture 2nd Gen 7nm GPU GDDR6 Memory Power Efficiency PCI Express 4.0 Support Video Streaming up to 8K Display Port 1.4 (HBR3) / DSC Radeon Software Radeon Boost Radeon Image Sharpening Radeon Anti-Lag AMD FidelityFx Async Compute Radeon Rays Audio + True Audio Next Radeon FreeSync 2 HDR Radeon VR Ready Premium

BIOS Support

Dual UEFI

Sapphire Features

TriXX Supported TriXX Boost Software BIOS Switch Max Boost Power Design ARGB LED Logo, Lightstrip, Backplate Logo & Fans Optional Fan Glow ARGB support NITRO Glow ARGB Audio Visualization Fan Check Free Flow VR Friendly Intelligent Fan Control Precision fan control Robust VRM Cooling Robust Memory Cooling Tri-X Cooling Technology Backplate (Tough Metal Backplate) Two-Ball Bearing Fan Quick Connect Fuse Protection Dual BIOS

System Requirement

Recommended 650 Watt Power Supply (Minimum 600 Watt Power Supply). 2 x 8-pin Power Connector. PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Minimum 8GB of system memory. 16GB recommended.
