TDP

391 W

Basklocka

2116 MHz

CUDA-kärnor

5120

Boost-klocka

2324 MHz

Minne

16 GB

Minnestyp

GDDR6

Max antal skärmar

4

Minneshastighet

18 Gbps

Arkitektur

RDNA 2

Buss

PCIe 4.0 x16

Max upplösning

HDMI: 7680×4320 DisplayPort1.4: 7680×4320

Displayutgångar

1x HDMI 3x DisplayPort

Övriga specifikationer

OS

Linux, Windows 7*, Windows 10, and Windows 11. 64-bit operating system required *Does not support all features including but not limited to Hardware Raytracing

Game Index

4K

Cooler Type

3 Fans

Form Factor

2.7 slot, ATX Dimension: 320(L)X 134.85(W)X 58.4 (H)mm

AMD Features

AMD RDNA 2 Gaming Architecture DirectX 12 Ultimate Hardware Raytracing 7nm GPU GDDR6 Memory PCI Express 4.0 Support AMD FreeSync Technology DisplayPort 1.4 with DSC HDMI Video Streaming up to 8K Radeon VR Ready Premium AMD FidelityFX AMD FidelityFX Super Resolution (FSR) AMD Radeon Super Resolution Radeon Image Sharpening Radeon Anti-Lag Radeon Software Game Driver Optimizations High Performance 4K Gaming

BIOS Support

Dual UEFI

Infinity Cache

128MB

Ray Accelerators

80

Sapphire Features

Dual BIOS Max Boost TriXX Software Switch Premium Digital Power Design Fuse Protection High TG Copper PCB Optimized Composite Heatpipe Tri-X Cooling Technology Intelligent Fan Control Precision Fan Control Backplate with ARGB Metal Backplate with Thermal Pad ARGB Fans Two-Ball Bearing Fans Hybrid Fan Blade Wave Fin Design V Shape Fin Design for GPU Cooling Integrated Cooling Module TriXX Supported Fan Check Fan Quick Connect Graphics Card Supporter TriXX Boost NITRO Glow External RGB LED MB Synchronization

System Requirement

Minimum 850 Watt Power Supply 2 x 8-pin + 1 x 6-pin Power Connector. PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Minimum 8GB of system memory. 16GB recommended.
