AMD G-series GX-424CC quad-core 2.4 GHz processor with Radeon graphics
Dimensioner
185.2 (H)
298.2 (W)
235.4(D) mm 7.29 (H)
11.74 (W)
9.27(D) inch
3.5"-fack
8
Ethernet-portar
2
Värdanslutning
Ethernet
Max Ethernet-hastighet
10 Gbps
Övriga specifikationer
USB
5 x USB 3.2 Gen 1 port (Front: 1, Rear: 4) Support USB printer, pen drive, and USB UPS etc.
DRAM
TVS-863+-8G: 8GB DDR3L-1600 x 1 TVS-863+-16G: 16GB DDR3L-1600 (8GB x 2) Total memory slots: 2 Memory expandable up to: 16 GB (8GB x2) NOTE: For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide.
HDMI
2 (Mirrored Display), 1.4a Note: 4K video playback and transcoding are not supported
Buttons
Power/Status, USB One-Touch-Backup, reset
TVS-863
Ethernet cable x 2 Power cord
Humidity
5~95% RH non-condensing, wet bulb: 27˚C
TVS-863+
Ethernet cable x 2 10 Gigabit network cable x 1
LCD Panel
Mono-LCD display with backlight, Enter and Select buttons for configuration
PCIe Slot
1 (PCIe Gen2 x 4)
Form Factor
Tower
IR Receiver
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
QNAP RM-IR002 and MCE-compatible remotes
Temperature
0-40˚C
Alarm Buzzer
System warning
Flash Memory
512MB DOM
Power Supply
ATX 250W, 110-240V AC, 50-60Hz, 5A
Sound Level*
Sound pressure (LpAm): 21.3 dB(A)
Secure Design
Kensington security slot for theft prevention
LED Indicators
Status, LAN, USB, HDD 1-8
Hard Disk Drive
8 x 3.5”or 2.5”SATA 6Gb/s, SATA 3Gb/s hard drive or SSD NOTE: 1. The system is shipped without HDD. 2. For the HDD compatibility list, please visit compatibility
Hard Drive Tray
8 x Hot-swappable tray
Power Consumption(W)
S3 sleep: 2.84W HDD standby: 48.21W In operation: 77.60W (with 8 x 2TB HDDs installed)
Playback videos, music, photos on yout TV with Kodi via HDMI output Watch various online contents such as Flickr, Picasa, Shoutcast, and more. Web browser (Chrome, Firefox) Supports USB keyboard and mouse Supports QNAP Qremote app and the official Kodi remote app Supports user login permissions Note: - The playback and quality of some video files may be affected due to the CPU and GPU decoding abilities. - 4K video playback and transcoding are not supported
Yes
TCP/IP (IPv4 & IPv6: Dual Stack) ♯ Dual Gigabit NICs with jumbo frame (failover, multi-IP settings, port trunking/NIC teaming) Service binding based on network interfaces Proxy server (Squid available in App Center) Proxy client DHCP client, DHCP server Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC UPnP & Bonjour Discovery USB Wi-Fi 802.11ac adapter support ♯ Not all IPv6 services are supported.
