TVS-671

Typ

NAS

Vikt

6.18 kg

Kylning

2 x quiet cooling fan (9 cm, 12V DC)

Kontroller

TVS-671-i3-4G: Dual-core Intel Core i3-4150 3.5 GHz Processor TVS-671-i5-8G: Quad-core Intel Core i5-4590S 3.0 GHz Processor (Turbo boost to 3.7 GHz)

Dimensioner

175 (H) 257 (W) 235 (D) mm 6.89 (H) 10.12 (W) 9.25 (D) inch

3.5"-fack

6

Ethernet-portar

1

Värdanslutning

Ethernet

Övriga specifikationer

USB

3x USB 3.2 Gen 1 port (front: 1, rear: 2) 2x USB 2.0 port (rear) Support USB printer, pen drive, USB hub, and USB UPS etc.

DRAM

TVS-671-i3-4G System memory: 4 GB DDR3 RAM Memory module pre-installed: 2 GB x2 Total memory slots: 2 Memory expandable up to: 16 GB (8GB x2) TVS-671-i5-8G System memory: 8 GB DDR3 RAM Memory module pre-installed: 4 GB x2 Total memory slots: 2 Memory expandable up to: 16 GB (8GB x2) NOTE: 1. When upgrading RAM, the original RAM module in the upgradable slot must be removed. 2. For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide.

HDMI

1

Buttons

System: Power button and reset button

TVS-671

Ethernet cable x 4 Power cord x 1

LAN Port

4 x Gigabit RJ-45 Ethernet port (Expandable up to 8 x 1 Gb LAN or 4 x 10 Gb + 4 x 1 Gb LAN by installing optional dual-port 10 Gb and 1 Gb network card) Note: 1. For the optional network card compatibility list, please visit Compatibility list of Expansion Card 2. For the information of network card installation, please refer to chapter 6 in the Turbo NAS Hardware Manual.

PCIe Slot

2 (1* PCIe Gen3 x8, 1* PCIe Gen2 x4)

Hard Drive

6 x 3.5-inch SATA 6Gb/s, SATA 3Gb/s hard drive or 2.5-inch SATA, SSD hard drive NOTE: 1. The standard system is shipped without hard drives. 2. For the HDD compatibility list, please visit Compatibility list
