89 (H)
482 (W)
534(D) mm 3.5 (H)
18.98 (W)
21.02(D) inch
3.5"-fack
12
Ethernet-portar
1
Värdanslutning
Ethernet
Övriga specifikationer
1.
Power Button 6. USB 3.2 Gen 1 Port x 4
2.
LED Indicators: 10 GbE, Status, LAN, Storage Expansion Port Status 7. HDMI
4.
USB 2.0 Port x 4 9. Power Connector
5.
Gigabit LAN x 4
DRAM
TVS-1271U-RP-PT-4G System memory: 4 GB DDR3 RAM Memory module pre-installed: 2 GB x2 Total memory slots: 4 Memory expandable up to: 32 GB (8GB x4) Note: When upgrading RAM to more than 20GB, the original 2GB RAM modules must be removed. TVS-1271U-RP-i3-8G: System memory: 8 GB DDR3 RAM Memory module pre-installed: 4 GB x2 Total memory slots: 4 Memory expandable up to: 32 GB (8GB x4) Note: When upgrading RAM to more than 24GB, the original 4GB RAM modules must be removed. TVS-1271U-RP-i5-16G: System memory: 16 GB DDR3 RAM Memory module pre-installed: 8 GB x2 Total memory slots: 4 Memory expandable up to: 32 GB (8GB x4) TVS-1271U-RP-i7-32G System memory: 32 GB DDR3 RAM Memory module pre-installed: 8 GB x4 Total memory slots: 4 For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide
HDMI
1
Buttons
System: Power button and reset button
LAN Port
4 x Gigabit RJ-45 Ethernet port (Expandable up to 8 x 1 Gb LAN or 4 x 10 Gb + 4 x 1 Gb LAN by installing optional dual-port 10 Gb and 1 Gb network card) Note: 1. For the optional network card compatibility list, please visit www.qnap.com/compatibility 2. For the information of network card installation, please refer to chapter 6 in the Turbo NAS Hardware Manual.
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
PCIe Slot
2 (1* PCIe Gen3 x8, 1* PCIe Gen3 x4)
USB/eSATA
4x USB 3.2 Gen 1 port (rear) 4x USB 2.0 port (rear) Support USB printer, pen drive, USB hub, and USB UPS etc.
Hard Drive
12 x 3.5-inch SATA 6Gb/s, SATA 3Gb/s hard drive or 2.5-inch SATA, SSD hard drive NOTE: 1. The standard system is shipped without hard drives. 2. For the hard drive compatibility list, please visit www.qnap.com/compatibility
Form Factor
2U, Rackmount
Temperature
0~40˚C
Alarm Buzzer
System warning
Flash Memory
512MB DOM
Power Supply
Input : 100-240V~, 50-60Hz, 7A-3.5A Output: 500W
Sound Level*
Sound pressure (LpAm): 45.0 dB(A)
TVS-1271U-RP
Ethernet cable x 4 Power cord x 2
Hard Disk Tray
12 x hot-swappable and lockable tray
LED Indicators
Status, 10 GbE, LAN, storage expansion port status
Relative Humidity
5~95% non-condensing, wet bulb: 27˚C.
Internal Cache Port
Two mSATA port on board for read caching Note: The standard system is shipped without mSATA flash module. For the optional mSATA flash module, please visit http://shop.qnap.com/
Power Consumption (W)
HDD Standby: TVS-1271U-RP-PT-4G: 88.88 TVS-1271U-RP-i3-8G: 87.89 TVS-1271U-RP-i5-16G: 88.91 TVS-1271U-RP-i7-32G: 89.82 In Operation: TVS-1271U-RP-PT-4G: 173.38 TVS-1271U-RP-i3-8G: 176.27 TVS-1271U-RP-i5-16G: 174.64 TVS-1271U-RP-i7-32G: 176.42 (with 12 x WD WD20EFRX hard drive installed)
TCP/IP: IPv4 & IPv6(1) Multiple NICs with Jumbo Frame (Failover, Multi-IP Settings, Port Trunking/NIC Teaming ) Service Binding Based on Network Interfaces Proxy Client, Proxy Server DHCP Client, DHCP Server NTP Server** Protocols: CIFS/SMB, SMB2.1**, SMB3.0 (Encryption only)**, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC UPnP & Bonjour Discovery USB Wi-Fi Adapter Support
Yes
Multi-window, Multi-tasking based System Management Movable Icons and Personalized Desktop Smart Toolbar and Dashboard for Neat Display on System Status Login Screen with Personalized Photo-wall Style Smart Fan Control Dynamic DNS (DDNS) SNMP (v2 & v3) Resource Monitor Network Recycle Bin for File Deletion via CIFS/SMB, AFP and File Station - Automatic Cleanup - File Type Filter Comprehensive Logs (Events & Connection) Syslog Client/Server System Settings Backup and Restore Restore to Factory Default Mobile App: Qmanager for Remote System Monitoring & Management
