QNAP

TS-EC1679U-SAS-RP

Name: TS-EC1679U-SAS-RP
Brand: QNAP

Art.nr: TS-EC1679U-SAS-RP

Specifikationer

Produktsida

Typ: NAS
Vikt: 18.3 kg
Kylning: 3 x 6 cm smart cooling fan
Kontroller: Quad Core Intel Xeon E3-1245 v2 Processor 3.4 GHz
Dimensioner: 130 (H) 442.4 (W) 528.3(D) mm 5.12 (H) 17.42 (W) 20.80(D) inch
3.5"-fack: 16
Ethernet-portar: 3
Värdanslutning: Ethernet
Diskgränssnitt: SAS
Max Ethernet-hastighet: 10 Gbps

Övriga specifikationer

1.: Power Button 6. USB 3.2 Gen 1 Port x 2
2.: LED Indicators: 10 GbE, Status, LAN, Storage Expansion Port Status 7. Password & Network Settings Reset Button
3.: Gigabit LAN x 4 8. Storage Expansion Port x 2
4.: Expansion Slot x 2 9. Power Connector
5.: USB 2.0 Port x 4
USB: 2x USB 3.2 Gen 1 port (rear) 4x USB 2.0 port (rear) Support USB printer, pen drive, USB hub, and USB UPS etc.
Memory: System memory: 8 GB DDR3 ECC RAM Memory module pre-installed: 4 GB x2 Total memory slots: 4 Memory expandable up to: 32 GB (8GB x4) Note: When upgrading RAM to more than 24GB, the original 4GB RAM modules must be removed. For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide
Buttons: System: Power button and reset button
LAN Port: 4 x Gigabit RJ-45 Ethernet port (Expandable up to 8 x 1 Gb LAN or 4 x 10 Gb + 4 x 1 Gb LAN by installing optional dual-port 10 Gb and 1 Gb network card) NOTE: For the optional network card compatibility list, please visit Compatibility list of Expansion Card For the information of network card installation, please refer to chapter 6 in the Turbo NAS Hardware Manual.

Priser hos återförsäljare

Butik	Logotyp	Pris	Lager
Inga aktuella priser tillgängliga.

Recensioner

Laddar recensioner…

Hard Drive

16 x 3.5-inch SAS/SATA 6Gb/s, SAS/SATA 3Gb/s hard drive or 2.5-inch SAS/ SATA, SSD hard drive NOTE: The standard system is shipped without hard drives. For the hard drive compatibility list, please visit Compatibility list

Form Factor

3U, Rackmount

Alarm Buzzer

System warning

Flash Memory

512MB DOM

Power Supply

Input: 100-240V AC,50-60Hz Output: 600W

Expansion Slot

2 (for network and storage expansion)

LED Indicators

Status, 10 GbE, LAN, storage expansion port status

Hard Drive Tray

16 x hot-swappable and lockable tray

Sound Level (dB)

Standby: 54.5dB (low fan speed) In operation: 62.2 dB (medium fan speed) (with16 x WD30EZRX-00MMMB0 hard drive installed)

Relative Humidity

5~95% RH non-condensing, wet bulb: 27˚C

TS-EC1679U-SAS-RP

CD-ROM Ethernet cable x 4

Power Consumption (W)

In Operation: 368 W (with 16 x Seagate ST3600057SS hard drive installed)

Storage Expansion Port

2 (rear)

Remark: The TS-x79 rack mount models comply with ANSI/EIA-RS-310-D rack mounting standards. Before purchasing the server racks for these models, please make sure the server racks conform to the following criteria: 1. Rack size Mounting post width : ≥ 450mm Panel width : ≥ 485mm Mounting post depth : 650mm~850mm 2. The optional rack kits for the TS-x79 rack mount models are only compatible with square-hole server racks.

Yes

Multi-window, Multi-tasking based System Management Movable Icons and Personalized Desktop Smart Toolbar and Dashboard for Neat Display on System Status Smart Fan Control Dynamic DNS (DDNS) SNMP (v2 & v3) Resource Monitor Network Recycle Bin for File Deletion via CIFS/SMB and AFP Automatic Cleanup File Type Filter Comprehensive Logs (Events & Connection) Syslog Client Firmware Live Update System Settings Backup and Restore Restore to Factory Default Mobile App Qmanager for Remote Monitoring

Yes
