TS-453BT3

Typ

NAS

Vikt

2.51 kg

Kylning

System: 1 x 120mm

M.2-platser

2

Kontroller

Intel Celeron J3455 4-core/4-thread processor, burst up to 2.3 GHz

Dimensioner

168 170 226 mm

3.5"-fack

4

Ethernet-portar

13

Värdanslutning

Ethernet

Diskgränssnitt

SATA + M.2 NVMe

Max Ethernet-hastighet

10 Gbps

Övriga specifikationer

Buttons

Power, USB copy, Reset, Capacitive touch buttons (select, enter)

IR Sensor

(RM-IR004, RM-IR002, & MCE)

PCIe Slot

1 x PCIe Gen 2 (x2), pre-installed with a QM2 expansion card (QM2-2S10G1TB) that includes a 10GbE 10GBASE-T port and two M.2 SATA SSD slots. The M.2 SATA SSD slots on this QM2 card only support M.2 2280 SATA 6Gb/s SSD, please check the compatibilities before purchase. PCIe bandwidth limitations will restrict the NAS 10GbE performance.

Audio Input

- (No longer available on units manufactured on or after 2021/1/1)

Form Factor

Tower

HDMI Output

2, HDMI 1.4b (up to 3840 x 2160 @ 30Hz)

Jumbo Frame

Yes

Memory Slot

2 x SODIMM DDR3L For dual-DIMM configuration, you must use a pair of identical DDR3L modules.

Audio Output

- (The line out jack and speaker are no longer available on units manufactured on or after 2021/1/1)

Flash Memory

4GB (Dual boot OS protection)
