Hot-swappable fan module (60*60*38mm; 16000RPM/12v/2.8A x 3)
Dimensioner
132
446.2
618 mm Excludes ear hook and the protruding part of the Power Supply Unit.
3.5"-fack
16
Värdanslutning
SAS
Diskgränssnitt
SATA + SAS
Övriga specifikationer
QES
Yes
EJ1600
Mini SAS external cable x2 (SFF-8088 to SFF-8088)，0.5M: CAB-SAS05M-8088 Power cord x 2
Buttons
Power / Reset
Management
The functions listed below are managed via the QNAP QES operating system. Support for hard disk’s S.M.A.R.T. capacity RAID expansion enclosure LED identifier Location indication of RAID expansion enclosure Location indication of hard disks on RAID expansion enclosure Smart fan control In-band firmware update The disks, RAID Groups, storage pools, and volumes in the RAID expansion enclosures are configured via the QES operating system. Upto 1PB Single Volume Support for multiple RAID groups in a storage pool to ensure data safety Online storage pool expansion Online volume expansion Block-based iSCSI LUN Support for thin-provisioned volume with space reclamation Support for thin-provisioned iSCSI LUN with space reclamation
Form Factor
3U Rackmount
Hot-swappable
Yes
LED Indicators
System Power LED (Green): on/off System Status (Green/ Orange): in operation, system errors, low power, degraded RAID mode, memory failure, fan/power supply failure, system/disk temperature too high, storage pool reaching threshold value, system performing take-over, power supply unit unplugged LCD Status Display (Two-digit number): Status of JBOD connection
System Warning
Buzzer
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
Weight (Gross)
33.8 kg
Power Supply Unit
Redundant/ Hot Swap ATX Power Supply, 450W, 90-240Vac~, 50-60Hz
Relative Humidity
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Standard Warranty
5
Storage Temperature
-20 - 70°C (-4°F - 158°F)
Supports Multi-path
Yes
Operating Temperature
0 - 40 °C (32°F - 104°F)
Supports JBOD cascading
Yes
Dual-controller design (HA)
Yes
Power Consumption: Operating Mode, Typical
344.19 W Tested with drives fully populated.
EJ1600 Mini SAS external cable x2 (SFF-8088 to SFF-8088)，0.5M: CAB-SAS05M-8088 Power cord x 2
EJ1600 Mini SAS external cable x2 (SFF-8088 to SFF-8088)，0.5M: CAB-SAS05M-8088 Power cord x 2
Superior High Availability Dual controller, dual-loop architecture to tolerate the failure of a single node Dual back-end IO paths (dual controller configuration) Topology: Single controller, single Single controller, multiple path, loop Dual-controller, single path Dual-controller, multiple path, loop Scalability Support disks up to 16 Support SATA HDD / SSD by optional SAS/SAS Interposer (LSI LSISS9252) Support cascade JBOD configuration to connect more JBODs, up to 6 sets Superior FRU Design Hot swappable PSU module, disks and controller module, for easier maintenance and deployment Dual Slim type PSU module
Yes
The functions listed below are managed via the QNAP QES operating system. Support for hard disk’s S.M.A.R.T. capacity RAID expansion enclosure LED identifier Location indication of RAID expansion enclosure Location indication of hard disks on RAID expansion enclosure Smart fan control In-band firmware update The disks, RAID Groups, storage pools, and volumes in the RAID expansion enclosures are configured via the QES operating system. Upto 1PB Single Volume Support for multiple RAID groups in a storage pool to ensure data safety Online storage pool expansion Online volume expansion Block-based iSCSI LUN Support for thin-provisioned volume with space reclamation Support for thin-provisioned iSCSI LUN with space reclamation
Yes
Expansion Enclosure Management The functions listed below are managed via the QNAP QES operating system. Support for hard disk’s S.M.A.R.T. capacity RAID expansion enclosure LED identifier Location indication of RAID expansion enclosure Location indication of hard disks on RAID expansion enclosure Smart fan control In-band firmware update The disks, RAID Groups, storage pools, and volumes in the RAID expansion enclosures are configured via the QES operating system. Upto 1PB Single Volume Support for multiple RAID groups in a storage pool to ensure data safety Online storage pool expansion Online volume expansion Block-based iSCSI LUN Support for thin-provisioned volume with space reclamation Support for thin-provisioned iSCSI LUN with space reclamation
Expansion Enclosure Management The functions listed below are managed via the QNAP QES operating system. Support for hard disk’s S.M.A.R.T. capacity RAID expansion enclosure LED identifier Location indication of RAID expansion enclosure Location indication of hard disks on RAID expansion enclosure Smart fan control In-band firmware update The disks, RAID Groups, storage pools, and volumes in the RAID expansion enclosures are configured via the QES operating system. Upto 1PB Single Volume Support for multiple RAID groups in a storage pool to ensure data safety Online storage pool expansion Online volume expansion Block-based iSCSI LUN Support for thin-provisioned volume with space reclamation Support for thin-provisioned iSCSI LUN with space reclamation High Availability Based On Dual Active Controller / Dual Loop Superior High Availability Dual controller, dual-loop architecture to tolerate the failure of a single node Dual back-end IO paths (dual controller configuration) Topology: Single controller, single Single controller, multiple path, loop Dual-controller, single path Dual-controller, multiple path, loop Scalability Support disks up to 16 Support SATA HDD / SSD by optional SAS/SAS Interposer (LSI LSISS9252) Support cascade JBOD configuration to connect more JBODs, up to 6 sets Superior FRU Design Hot swappable PSU module, disks and controller module, for easier maintenance and deployment Dual Slim type PSU module High Availability Based On Dual Active Controller / Dual Loop Superior High Availability Dual controller, dual-loop architecture to tolerate the failure of a single node Dual back-end IO paths (dual controller configuration) Topology: Single controller, single Single controller, multiple path, loop Dual-controller, single path Dual-controller, multiple path, loop Scalability Support disks up to 16 Support SATA HDD / SSD by optional SAS/SAS Interposer (LSI LSISS9252) Support cascade JBOD configuration to connect more JBODs, up to 6 sets Superior FRU Design Hot swappable PSU module, disks and controller module, for easier maintenance and deployment Dual Slim type PSU module
