Typ

Fan

Vikt

0.005 kg

Luftflöde

237.9 m3/h

Fläktstorlek

140 mm

Antal fläktar

3

Fläktmodell

T30-140 Triple Pack

Fläkthastighet

0~2500 ± 10% RPM

Garanti

6 years

Dimensioner

140 × 140 × 30 mm

Lagertyp

VAPO bearing system

Övriga specifikationer

General Color

Grey

General UPC Code

886523003939 | 886523003946

General Model No.

PH-F140T30_BG | PH-F140T30_BG_3P

Triple Pack Screws

12x Fan screw12x Radiator screw UNC6-32 36 mm12x Radiator screw M4 36 mm

General PWM Connector

4-Pin Daisy-chain

General Blade Geometry

Seven-blades design

Technical Details MTFB

150.000 hours

Triple Pack Accessories

3x 4-Pin extension cable 500 mm

General PWM Cable Length

150 + 500 mm Extension cable

Triple Pack Gross Weight

1402 ± 5 g | 49.45 ± 0.17 oz

General D-RGB Cable Length

-

Technical Details Max. Power

6.72W

Technical Details Max. Current

0.56A

Technical Details Rated Voltage

12V

Technical Details Max. Noise Level

44.3 dBA

Technical Details Max. Air Pressure

5.41 mm H2O

Fan Profile Specifications Max. Power

W | 6.72 | 3.48 | 1.20

Fan Profile Specifications Max. Speed

RPM | 2500 ± 150 | 2000 ± 100 | 1200 ± 75

Fan Profile Specifications Max. Airflow

M3/H | 237.18 | 186.72 | 107.37

Fan Profile Specifications Max. Current

A | 0.56 | 0.29 | 0.10

Technical Details Operating Voltage Range

DC 10.2 - 13.2V
