Vikt

11.28 kg

Front I/O

1x USB-C 3.2 Gen 2 2x USB 3.0 Microphone, Headphone D-RGB Mode Button D-RGB Color Button Power Button

Chassityp

Mid Tower

Material

Steel chassis, Tempered glass

Dimensioner

239 × 477 × 528 mm

Formfaktor

E-ATX, ATX, Micro-ATX, Mini-ITX

Max 120 mm-fläktar

8

Max 140 mm-fläktar

0

2.5"-fack

4

3.5"-fack

3

Max GPU-längd

440 mm

Max PSU-längd

230 mm

Sidopanel

Tempered Glass

Expansionsplatser

7

Max kylarhöjd

180 mm

Radiatorstöd (topp)

360 mm

Övriga specifikationer

Extra Screws

22x Mainboard | SSD screws 4x Power supply screws 4x Thumb screws 12x Case screws 1x Motherboard stand-off 1x Stand-off removal tool

Extra Warranty

5 Years limited | Learn more

General UPC Code

886523302957

General Model No.

PH-NV523TG_DMW01

Extra Gross Weight

13.97 kg | 30.8 lbs

Fans 120 | 140 Top

3x | -

Extra Accessory Box

6x Zip ties 1x GPU support bracket

Fans 120 | 140 Rear

1x | -

Fans 120 | 140 Side

3x | -

Fans 120 | 140 Front

- | -

Fans 120 | 140 Bottom

1x | -

Clearance Top Radiator

Length x Width | 134 x 430 x 62 mm | 5.27 x 16.92 x 2.44 in

Clearance Rear Radiator

Length x Width | 132 x 170 mm | 5.19 x 6.69 in

Clearance Side Radiator

Length x Width | 130 x 420 x 62 mm | 5.11 x 16.53 x 2.44 in

Extra Scope of Delivery

1x NV5 chassis

Clearance Front Radiator

Length x Width | - | -

Radiators 120 | 140 Rear

120 | -

Radiators 120 | 140 Side

Max. 360 | -

Radiators 120 | 140 Bottom

- | -

General Vertical GPU Support

3-slots | Riser Cable sold separately
