RGB

ARGB

Typ

AIO 240mm

Ljudnivå

30.2 dBA

Vikt

1.5 kg

Luftflöde

109.2 m3/h

Fläktstorlek

120 mm

Antal fläktar

1

Fläktmodell

D30-120 D-RGB PWM

Fläkthastighet

250 - 2000 ± 10% RPM

Material

Aluminum | ABS Plastic | Copper, Copper | ABS, CIIR rubber | Braided sleeves

Garanti

5 years

Pumphastighet

3100 RPM ± 10% (100% Duty Cycle)

Dimensioner

277 × 120 × 27 mm

Slanglängd

400mm

Radiatorstorlek

240 mm

Statiskt tryck

3.01 mmH2O

Sockelkompatibilitet

Intel: LGA 115x, LGA 1200, LGA 1700, LGA 2011, LGA 2011-3, LGA 2066; AMD: AM4, AM5

Övriga specifikationer

Extra Screws

8x 33 mm 6-32 UNC radiator screws 8x 35 mm 6-32 UNC radiator screws 8x 6 mm 6-32 UNC radiator screws

General Color

Black

General UPC Code

886523003083

General Model No.

PH-GO240D30_DBK01

Extra Gross Weight

2.30 kg | 5.07 lbs

Pump Details Power

12V | 0.38A - 0.45A | 4.56W - 5.4W

Extra Accessory Box

3x Tube clip 1x SATA to 2-pin pump adapter 1x D-RGB mainboard adapter 600 mm 1x PH-NDC thermal paste 1x Installation guide

Fans 2x Included MTFB

150.000 Hours

Tube Details Diameter

10.5 mm OD | 0.41 in OD

Extra Mounting Hardware

4x AM4 | AM5 Stand-Off screws 4x LGA 1700 Stand-Off screws 4x LGA 115X | 1200 Stand-Off screws 4x LGA 2011 | 2066 Stand-Off screws 4x Thumb nuts 1x AM4 | AM5 Bracket 1x LGA 115X | 1200 | 1700 | 2011 | 2066 Bracket 1x LGA 115X | 1200 | 1700 Metal back plate

General Pump Dimensions

Length x Width x Height | 76 x 64 x 51.4 mm | 2.99 x 2.51 x 2.02 in

Tube Details Tube Clips

3x

Extra D30 Fan Components

1x Corner clip connector 3x Corner clip 1x Bridge clip connector 1x Bridge clip 2x Screw cover bridge 2x Screw cover L 2x Screw cover R

Pump Details Sound Level

20.0 dBA

Pump Details Pump DC Cable

490 mm

Fans 2x Included PWM Connector

4-Pin Daisy-chain

Pump Details D-RGB Cable Length

500 + 90 mm

Fans 2x Included D-RGB Connector

3-Pin D-RGB Daisy-chain

Fans 2x Included PWM Cable Length

700 mm | 27.55 in | 700 mm | 27.55 in

Fans 2x Included D-RGB Cable Length

600 + 100 mm | 23.62 + 3.93 in
