Vikt

4.2 kg

Front I/O

1x USB-C GEN 2 1x USB 3.0 D-RGB Mode Button D-RGB Color Button Power Button

Chassityp

SFF

Material

Aluminum panels, Steel chassis, Tempered glass Infinity Mirror

Dimensioner

211 × 244 × 272 mm

Formfaktor

Mini-ITX

Max 120 mm-fläktar

2

Max 140 mm-fläktar

2

2.5"-fack

1

3.5"-fack

0

Max GPU-längd

324 mm

Sidopanel

Tempered Glass

Expansionsplatser

3

Max kylarhöjd

72 mm

Radiatorstöd (topp)

240 mm

Övriga specifikationer

Extra Screws

9x Mainboard | SSD screws 4x Power supply screws 2x Top panel standoff (spare) 2x Rear cover screws 1x Screwdriver (PH2)

Extra Warranty

5 Years limited | Learn more

General UPC Code

886523302308

General Model No.

PH-ES121XT_DBK01

Extra Gross Weight

5.00 kg | 11.02 lbs

Fans 120 | 140 Top

2x | 2x

Extra Accessory Box

6x Zip ties 1x Rear cover - Air boost 1x Rear cover - Liquid cooled 1x Phanteks badge

Fans 120 | 140 Rear

- | -

Fans 120 | 140 Side

- | -

Fans 120 | 140 Front

- | -

Fans 120 | 140 Bottom

- | -

Clearance Top Radiator

Radiator + Fan Thickness | 28 + 32 mm | 1.10 + 1.25 in

Clearance Side Radiator

Length x Width | -

Extra Scope of Delivery

1x Evolv Shift XT chassis 1x SSD bracket

Extra Accessory Envelope

1x Top filters (set of 3)

Radiators 120 | 140 Rear

- | -

Radiators 120 | 140 Side

- | -

Clearance Bottom Radiator

Length x Width | -

Radiators 120 | 140 Bottom

- | -

General Vertical GPU Support

3-slots pre-installed | Riser Cable PCI-e 4.0 X16
