Vikt

13.19 kg

Front I/O

1x USB-C GEN 2 4x USB 3.0 Microphone, Headphone Combo Reset Button Power Button

Chassityp

Full Tower

Material

Steel chassis, Tempered glass

Dimensioner

240 × 580 × 560 mm

Formfaktor

XL-ATX, SSI-EEB, E-ATX, ATX, Micro-ATX, Mini-ITX

2.5"-fack

11

3.5"-fack

10

Max GPU-längd

503 mm

Sidopanel

Tempered Glass

Expansionsplatser

11

Max kylarhöjd

195 mm

Radiatorstöd (topp)

360 mm

Radiatorstöd (front)

420 mm

Övriga specifikationer

Fans Top

3x | 3x

Fans Rear

1x | -

Fans Side

4x | -

Fans Front

4x | 3x

Extra Screws

18x Mainboard | SSD screws 5x Power supply screws 12x Fan screws 1x Motherboard stand-off 2x HDD cage screws

Fans Bracket

3x | -

Extra Warranty

5 Years limited | Learn more

Radiators Rear

120 | -

Radiators Side

Max. 480 | -

Fans Total Fans

120 mm | 140 mm | 15x | 6x

General UPC Code

886523302735

General Model No.

PH-ES620PTG_BK02

Radiators Bracket

- | -

Extra Gross Weight

15.47 kg | 34.11 lbs

Clearance Mainboard

Height x Width | Max. 375 x 330 mm | 14.76 x 12.99 in

Extra Accessory Box

6x Zip ties 1x GPU support bracket 1x Server PSU bracket 1x Phanteks case badge

Clearance Top Radiator

Length x Width | 120 x 475 mm (Max. 55 mm mainboard height) | 4.72 x 18.70 in (Max. 2.16″ mainboard height)

Clearance Side Radiator

Length x Width x Height | 134 x 525 x 35 mm | 5.27 x 20.66 x 1.37 in

Extra Scope of Delivery

1x Enthoo Pro II Server Edition chassis 1x Left side bracket 3x SSD bracket 4x HDD bracket

Clearance Front Radiator

Length x Width | 142 x 475 mm | 5.59 x 18.70 in

General Vertical GPU Support

3-slots | Riser Cable sold separately
