Vikt

9.63 kg

Front I/O

1x USB-C 3.2 Gen 2 2x USB 3.0 Microphone, Headphone D-RGB Mode Button D-RGB Color Button Power Button

Chassityp

Mid Tower

Material

Steel chassis, Tempered glass

Dimensioner

240 × 500 × 515 mm

Formfaktor

E-ATX, ATX, Micro-ATX, Mini-ITX

Max 120 mm-fläktar

7

Max 140 mm-fläktar

7

2.5"-fack

9

3.5"-fack

10

Max GPU-längd

435 mm

Max PSU-längd

195 mm

Sidopanel

Tempered Glass

Expansionsplatser

7

Max kylarhöjd

185 mm

Radiatorstöd (topp)

360 / 280 mm

Radiatorstöd (front)

420 / 360 mm

Övriga specifikationer

Extra Screws

22x Mainboard | SSD screws 7x Power supply screws 8x HDD locking screws 12x Thumb screws 8x Fan screws 8x Case screws 1x Motherboard stand-off 3x Riser cable screws 1x Stand-off removal tool

Extra Warranty

5 Years limited | Learn more

General UPC Code

886523302650

General Model No.

PH-EC500GA_DBK01B

Extra Gross Weight

12.10 kg | 26.7 lbs

Fans 120 | 140 Top

3x | 3x

Extra Accessory Box

6x Zip ties 1x GPU anti-sag bracket 1x Vertical GPU mount

Fans 120 | 140 Rear

1x | 1x

Fans 120 | 140 Side

- | -

Fans 120 | 140 Front

3x | 3x

Fans 120 | 140 Bottom

- | -

Clearance Top Radiator

Length x Width | ? x 70 mm | ? x 2.75 in

Clearance Side Radiator

Length x Width | -

Extra Scope of Delivery

1x Eclipse G500A chassis 3x SSD bracket 2x HDD bracket

Clearance Front Radiator

Length x Width | 142 x 475 mm | 5.59 x 18.70 in

Radiators 120 | 140 Rear

120 | -

Radiators 120 | 140 Side

- | -

Clearance Bottom Radiator

Length x Width | -

Radiators 120 | 140 Bottom

- | -

General Vertical GPU Support

3-slots | Riser Cable sold separately
