Typ

Fan

Ljudnivå

32.1 dBA

Vikt

0.35 kg

Luftflöde

121.9 m3/h

Fläktstorlek

140 mm

Antal fläktar

1

Fläktmodell

D30-140 | White Reverse Single Pack

Fläkthastighet

250~1800 ± 10% RPM

Garanti

3 years

Dimensioner

140 × 140 × 30 mm

Lagertyp

FDB (Fluid Dynamic Bearing)

Statiskt tryck

3.08 mmH2O

Övriga specifikationer

General UPC Code

Regular | Reverse | 886523002970 | 886523002994 | 886523003304 | 886523003328

General Model No.

Regular | Reverse | PH-F140D30_DRGB_PWM_WT01 | PH-F140D30_DRGB_PWM_WT01_3P | PH-F140D30R_DRGB_PWM_WT01 | PH-F140D30R_DRGB_PWM_WT01_3P

Single Pack Screws

4x Fan screw 4x UNC 6-32 radiator screw 36mm 4x M4 radiator screw 36mm 1x Corner clip cable 3x Corner clip 1x Bridge clip connector 1x Bridge clip 4x Screw cover corner (2L|2R) 2x Screw cover bridge

General PWM Connector

4-Pin Daisy-chain

Single Pack Accessory

1x D-RGB mainboard adapter

General Blade Geometry

Seven blades design

General PWM Cable Length

700 mm | 27.56 in

Single Pack Gross Weight

430 g | 15.16 oz

General D-RGB Cable Length

600 + 100 mm | 23.62 + 3.94 in

Technical Details Reverse MTFB

50.000 hours

Technical Details Reverse Max Power

≦ 1.8W

Technical Details Reverse LED Number

30

Technical Details Reverse Max Current

0.15A

Technical Details Reverse Rated Voltage

5~13.2V

Technical Details Reverse LED Rated Current

Max. 0.45A

Technical Details Reverse Operating Voltage Range

DC 5 ~ 13.2V
