WiFi

WiFi 6E

M.2-platser

6726

PCIe-platser

1x PCIe 5.0 x16 slot (PCIEX16_1), 2x PCIe 4.0 x16 slots (PCIEX16_2 and PCIEX16_3)

SATA-portar

4

Formfaktor

ATX

Minnestyp

DDR5

Displayutgångar

1x HDMI

Övriga specifikationer

Chipset AMD

B650E

LAN Realtek®

RTL8125BG 2.5G LAN

Audio Realtek®

ALC1220 Codec

General Warranty

3 years

Rear I/O USB 2.0

2

Wireless Bluetooth

V5.2

General EAN (Black)

5056547202822

General EAN (White)

5056547202815

General UPC (Black)

810074842884

General UPC (White)

810074842877

Rear I/O Audio jacks

5

Storage RAID for SATA

0/1/10

General Certifications

FCC, CE, WHQL, ErP/EuP Ready

Internal I/O POST LEDs

4

Integrated Graphics HDR

Supported

Rear I/O LAN (RJ45) port

1

Internal I/O Power button

1

Internal I/O Reset button

1

Memory Max Memory Support

128GB

Storage RAID for M.2 NVMe

0/1/10

Memory Memory Architecture

Dual-Channel

Rear I/O Clear CMOS button

1

General System Requirements

NZXT CAM software requires Microsoft Windows 11/10 operating system.

Internal I/O USB 2.0 header

3 (Up to 6 USB 2.0 ports)

General Model Number (Black)

N7-B65XT-B1

General Model Number (White)

N7-B65XT-W1

Integrated Graphics HDCP 2.3

max. resolution up to 4K 60Hz

Rear I/O USB 3.2 Gen 1 ports

4

Rear I/O USB 3.2 Gen 2 ports

2

Rear I/O BIOS Flashback button

1

Storage NVMe SSD as boot disks

Supported

Internal I/O USB 3.2 Gen1 header

2 (Up to 4 USB 3.2 Gen 1 ports)

Rear I/O Optical S/PDIF Out port

1

Expansion Slots M.2 Socket (Key E)

1 (supports Type 2230 Wi-Fi/BT PCIe Wi-Fi module)

Internal I/O 5V ARGB LED connector

2

Rear I/O USB 3.2 Gen 2 Type-C port

1

Memory Extreme Memory Profile (XMP)

Supported

Internal I/O 4-pin CPU_FAN connector

1

Internal I/O NZXT RGB LED connectors

4

Internal I/O 4-pin AIO_PUMP connector

1

Internal I/O 4-pin SYS_FAN connectors

5

Internal I/O 24-pin ATX power connector

1

Internal I/O Front panel audio connector

1

Rear I/O Wireless antenna SMA connectors

2

Integrated Graphics HDMI 2.1 TMD Compatible

1

Internal I/O 8+4-pin ATX 12V power connector

1

Internal I/O USB 3.2 Gen2x2 front panel header

1 (For USB Type-C)

Memory EXTended Profiles for Overclocking (EXPO)

Supported

Integrated Graphics Integrated AMD RDNA™ 2 graphics

Supported

CPU Supports AMD Socket AM5 for AMD Ryzen™ 9000, 8000, and 7000 Series Processors

Supported
