- Fan Support Top
- 3 x 120 mm / 3 x 140 mm
- Product Info EAN
- 5056547207636 (White) / 5056547207643 (Black) / 5056547208848 (White AU) / 5056547208855 (Black AU)
- Product Info UPC
- 810074847841 (White) / 810074847858 (Black) / 815671019493 (White AU) / 815671019509 (Black AU)
- Dimensions Volume
- 76.7 L
- Warranty Warranty
- 2 years
- Fan Support Bottom
- 3 x 120 mm / 3 x 140 mm
- Product Info Warranty
- 2 years
- Radiator Support Rear
- Up to 120 mm
- Front I/O Headset Jack
- 1
- Radiator Support Bottom
- Up to 360 mm
- Cooling Support Rear Fan
- 1 x 120 mm (1 included)
- Cooling Support Top Fans
- 3 x 120 mm / 3 x 140 mm
- Expansion Slots Vertical
- 0
- Front I/O USB 3.2 Type-A
- 2
- Included Fan Specs Model
- F140Q (Case Version) / F120Q (Case Version)
- Included Fan Specs Speed
- 1,350 ± 150 RPM
- General Power Supply Type
- ATX
- Product Info Model Number
- CM-H92FW-01 (White) / CM-H92FB-01 (Black) / CM-H92FW-02 (White AU) / CM-H92FB-02 (Black AU)
- Included Fan Specs Airflow
- 100.25 CFM / 60.2 CFM
- Cooling Support Bottom Fans
- 3 x 120 mm / 3 x 140 mm
- General Motherboard Support
- E-ATX (Up to 277 mm), ATX, Micro-ATX, Mini-ITX
- Included Fan Specs Quantity
- 3 / 1
- Cooling Support Top Radiator
- Up to 420 mm
- Fan Specs - F120Q (CV) Model
- F120Q (CV)
- Fan Specs - F120Q (CV) Noise
- 24.1 dBA
- Fan Specs - F120Q (CV) Speed
- 1,350 ± 150 RPM
- Fan Specs - F140Q (CV) Model
- F140Q (CV)
- Fan Specs - F140Q (CV) Noise
- 22.9 dBA
- Fan Specs - F140Q (CV) Speed
- 1,350 ± 150 RPM
- Cooling Support Rear Radiator
- Up to 120 mm
- Fan Specs - F120Q (CV) Airflow
- 60.2 CFM
- Fan Specs - F140Q (CV) Airflow
- 100.25 CFM
- Included Fan Specs Noise Level
- 22.9 dBA / 24.1 dBA
- Cooling Support Bottom Radiator
- Up to 360 mm
- Cooling Support Front-Right Fans
- 3 x 120 mm / 3 x 140 mm (3 included)
- Front I/O USB 3.2 Gen 2x2 Type-C
- 1
- Included Fan Specs Fan Connector
- 3-pin
- Dimensions Dimensions (H x W x D)
- 506 x 315 x 481 mm (19.9 x 12.4 x 18.9 in)
- Expansion & Drives 2.5" Drive Bays
- 4+2
- Expansion & Drives 3.5" Drive Bays
- 2
- Expansion & Drives Expansion Slots
- 7
- Included Fan Specs Static Pressure
- 1.4 mmH₂O / 1.05 mmH₂O
- Cooling Support Front-Right Radiator
- Up to 420 mm
- Fan Specs - F120Q (CV) Fan Connector
- 3-pin
- Fan Specs - F140Q (CV) Fan Connector
- 3-pin
- Clearance Top Radiator & Fan Thickness
- Up to 80 mm (360 mm) Up to 62 mm (420 mm)
- Clearance Top Radiator + Fan Thickness
- Up to 80 mm (360 mm) Up to 62 mm (420 mm)
- Fan Specs - F120Q (CV) Static Pressure
- 1.05 mmH2O
- Fan Specs - F140Q (CV) Static Pressure
- 1.4 mmH2O
- General Back-Connect Motherboard Support
- Yes (ATX)
- General Rear-Connecting Motherboard Support (BTF, Project Zero)
- Yes (ATX)
