- Fan Support Top
- 3 x 120 mm / 3 x 140 mm
- Product Info EAN
- 5056547207650 5056547207667 5056547208862 5056547208879
- Product Info UPC
- 810074847865 810074847872 815671019516 815671019523
- Dimensions Volume
- 76.7 L
- Warranty Warranty
- 2 years
- Fan Support Bottom
- 3 x 120 mm / 3 x 140 mm
- Radiator Support Rear
- Up to 120 mm
- Radiator Support Bottom
- Up to 360 mm
- Expansion Slots Vertical
- 0
- Product Info Model Number
- CM-H92FW-R1 CM-H92FB-R1 CM-H92FW-R2 CM-H92FB-R2
- Fan Specs - F120Q (CV) Model
- F120Q (CV)
- Fan Specs - F120Q (CV) Noise
- 24.1 dBA
- Fan Specs - F120Q (CV) Speed
- 1,350 ± 150 RPM
- Fan Specs - F120Q (CV) Airflow
- 60.2 CFM
- Fan Specs - F420 RGB Core Model
- F420 RGB Core
- Fan Specs - F420 RGB Core Noise
- 34.5 dBA
- Fan Specs - F420 RGB Core Speed
- 2,000 ± 200 RPM
- Fan Specs - F420 RGB Core Airflow
- 98.61 CFM
- Fan Specs - F120Q (CV) Fan Connector
- 3-pin
- Clearance Top Radiator & Fan Thickness
- Up to 80 mm (360 mm) Up to 62 mm (420 mm)
- Fan Specs - F120Q (CV) Static Pressure
- 1.05 mmH2O
- Fan Specs - F420 RGB Core Fan Connector
- 8-pin w/ splitter
- Fan Specs - F420 RGB Core Static Pressure
- 3.2 mmH2O
- General Rear-Connecting Motherboard Support (BTF, Project Zero)
- Yes (ATX)
