- Fan Support Top
- 3 x 120 mm / 3 x 140 mm
- Product Info EAN
- 5056547207674 (White) / 5056547207681 (Black) / 5056547208886 (White AU) / 5056547208893 (Black AU)
- Product Info UPC
- 810074847889 (White) / 810074847896 (Black) / 815671019530 (White AU) / 815671019547 (Black AU)
- Dimensions Volume
- 76.7 L
- Warranty Warranty
- 2 years
- Product Info Warranty
- 2 years
- Radiator Support Rear
- Up to 120 mm
- Front I/O Headset Jack
- 1
- Radiator Support Bottom
- Up to 360 mm
- Control Hub Fan Channels
- 3 x NZXT 8-pin (PWM only) / 1 x NZXT 8-pin (DC+PWM control) / 1 x 4-pin PWM (DC+PWM control)
- Control Hub RGB Channels
- 4 x NZXT 8-pin / 1 x NZXT RGB
- Cooling Support Rear Fan
- 1 x 120 mm (1 included)
- Cooling Support Top Fans
- 3 x 120 mm / 3 x 140 mm
- Expansion Slots Vertical
- 0
- Front I/O USB 3.2 Type-A
- 2
- Included Fan Specs Model
- F420 RGB Core / F120 RGB Core (Case Version)
- Included Fan Specs Speed
- 2,000 ± 200 RPM / 1,300 ± 130 RPM
- General Power Supply Type
- ATX
- Product Info Model Number
- CM-H92FW-P1 (White) / CM-H92FB-P1 (Black) / CM-H92FW-P2 (White AU) / CM-H92FB-P2 (Black AU)
- Included Fan Specs Airflow
- 98.61 CFM / 55.17 CFM
- Control Hub Max LED Support
- Each NZXT 8-pin channel supports a maximum of 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to NZXT 5 devices.
- Cooling Support Bottom Fans
- 3 x 120 mm / 3 x 140 mm (1 included)
- General Motherboard Support
- E-ATX (Up to 277 mm), ATX, Micro-ATX, Mini-ITX
- Included Fan Specs Quantity
- 2 / 1
- Cooling Support Top Radiator
- Up to 420 mm
- Cooling Support Rear Radiator
- Up to 120 mm
- Control Hub Specs Fan Channels
- 3 x NZXT 8-pin (PWM only) / 1 x NZXT 8-pin (DC+PWM control) / 1 x 4-pin PWM (DC+PWM control)
- Control Hub Specs RGB Channels
- 4 x NZXT 8-pin / 1 x NZXT RGB
- Included Fan Specs Noise Level
- 34.5 dBA / 26.1 dBA
- Control Hub System Requirements
- USB 2.0 Internal Header 8-pin PCIe Power
- Cooling Support Bottom Radiator
- Up to 360 mm
- Fan Specs - F420 RGB Core Model
- F420 RGB Core
- Fan Specs - F420 RGB Core Noise
- 34.5 dBA
- Fan Specs - F420 RGB Core Speed
- 2,000 ± 200 RPM
- Cooling Support Front-Right Fans
- 3 x 120 mm / 3 x 140 mm (1 included)
- Front I/O USB 3.2 Gen 2x2 Type-C
- 1
- Included Fan Specs Fan Connector
- 8-pin / 3-pin
- Control Hub Specs Max LED Support
- Each NZXT 8-pin channel supports a maximum of 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to NZXT 5 devices.
- Dimensions Dimensions (H x W x D)
- 506 x 315 x 481 mm (19.9 x 12.4 x 18.9 in)
- Fan Specs - F420 RGB Core Airflow
- 98.61 CFM
- Expansion & Drives 2.5" Drive Bays
- 4+2
- Expansion & Drives 3.5" Drive Bays
- 2
- Expansion & Drives Expansion Slots
- 7
- Included Fan Specs Static Pressure
- 3.2 mmH₂O / 1.27 mmH₂O
- Cooling Support Front-Right Radiator
- Up to 420 mm
- Fan Specs - F120 RGB Core (CV) Model
- F120 RGB Core (CV)
- Fan Specs - F120 RGB Core (CV) Noise
- 26.1 dBA
- Fan Specs - F120 RGB Core (CV) Speed
- 1,300 ± 130 RPM
- Control Hub Specs System Requirements
- USB 2.0 Internal Header 8-pin PCIe Power
- Clearance Top Radiator & Fan Thickness
- Up to 80 mm (360 mm) Up to 62 mm (420 mm)
- Clearance Top Radiator + Fan Thickness
- Up to 80 mm (360 mm) Up to 62 mm (420 mm)
- Fan Specs - F120 RGB Core (CV) Airflow
- 55.17 CFM
- Fan Specs - F420 RGB Core Fan Connector
- 8-pin
- General Back-Connect Motherboard Support
- Yes (ATX)
- Fan Specs - F420 RGB Core Static Pressure
- 3.2 mmH2O
- Fan Specs - F120 RGB Core (CV) Fan Connector
- 3-pin
- Fan Specs - F120 RGB Core (CV) Static Pressure
- 1.27 mmH2O
- General Rear-Connecting Motherboard Support (BTF, Project Zero)
- Yes (ATX)
