Vikt

4.8 kg

Front I/O

1x USB 3.2 Type-A, 1x USB 3.2 Gen2x2 Type-C

Chassityp

Micro-ATX Case

Material

SGCC steel, clear tempered glass (white), tinted tempered glass (black)

Formfaktor

ATX

2.5"-fack

3

3.5"-fack

1

Medföljande fläktar

Rear: 1 x 120 mm (1 x F120Q (CV) included)

Max GPU-längd

377 mm

Max PSU-längd

185 mm

Sidopanel

Tempered Glass

Expansionsplatser

4

Max kylarhöjd

170 mm

Radiatorstöd (topp)

Up to 240 mm

Övriga specifikationer

Fan Specs Model

F120Q (CV)

Fan Specs Noise

24.1 dBA

Fan Specs Speed

1,350 ± 150 RPM

Fan Support Top

2 x 120 mm / 2 x 140 mm

Product Info EAN

5056547207971 5056547207988 5056547203393 5056547203409

Product Info UPC

810074848039 810074848046 810074843508 810074843515

Dimensions Volume

35.0 L

Fan Specs Airflow

60.2 CFM

Fan Support Front

2 x 120 mm / 2 x 140 mm

Warranty Warranty

2 years

Fan Support Bottom

2 x 120 mm

Radiator Support Front

Up to 280 mm

Fan Specs Fan Connector

3-pin

Expansion Slots Vertical

0

Fan Specs Static Pressure

1.05 mmH2O

Product Info Model Number

CC-H31FW-01 CC-H31FB-01 CC-H31FW-02 CC-H31FB-02

Clearance Cable Routing Space

Up to 31.5 mm

Dimensions Height (with feet)

400 mm (15.75 in)

Clearance Top Radiator + Fan Thickness

Up to 70 mm

Clearance Front Radiator + Fan Thickness

Up to 63 mm

General Supports Rear-Connecting Motherboards (BTF, Project Zero)

Yes (Micro-ATX)
