RGB

RGB

Typ

Fan

Ljudnivå

33.88 dBA

Fläktstorlek

120 mm

Antal fläktar

1

Fläkthastighet

500 - 1,800 ± 180RPM

Material

Plastic, rubber, PCB

Dimensioner

120 × 120 × 26 mm

Lagertyp

Fluid Dynamic Bearing (FDB)

Övriga specifikationer

Fan Life Hours

60,000

Fan Life Years

6

Cooling Airflow

78.86 CFM

Cooling Bearing

Fluid Dynamic Bearing

General Warranty

2 years

Cooling Output LED

8 LEDs

RGB Controller Weight

52.8 g

Cooling Static Pressure

2.57 mm H2O

Key Specs Fan Connector

4-pin PWM

RGB Controller Mounting

2 × 3M Dual Lock

Cooling Power Consumption

12 V DC, 0.2 A, 2.4 W

RGB Controller Dimensions

63.2 × 53.2 × 12.8 mm

Black Variant Model Number

RF-C12SF-B1

RGB Controller Connections

1 × USB 2.0 Header, 1 × SATA

RGB Controller Material(s)

Plastic, PCB, Magnets

White Variant Model Number

RF-C12SF-W1

Key Specs Fan Rated Voltage

12 V DC, 0.2 A, 2.4 W

Connections & Cable Length PWM

4-pin PWM Fan Cable – 600mm x1

RGB Controller Input Connector

12V DC / 2.6A

Connections & Cable Length NZXT RGB

4-pin NZXT RGB Cable – 600mm x1

RGB Controller RGB Lighting Channels

3

RGB Controller Output Channel Voltage

5V DC

System Requirements Internal Connector

Requires a USB 2.0 internal connector

System Requirements System Requirement

PC with available NZXT RGB lighting connector and Windows 11/10 operating system.

RGB Controller Lighting channels support

Up to 40 LEDs per channel and up to 120 LEDs combined total for the 3 channels
