Modulär

Full

Effekt

850 W

Dimensioner

125 × 100 × 63mm

Formfaktor

SFX

Skydd

OVP (Over Voltage Protection), UVP (Under Voltage Protection), SCP (Short Circuit Protection), OTP (Over Temperature Protection), OPP (Over Power Protection), OCP (Over Current Protection)

Övriga specifikationer

Fan Specs Size

92 mm

Fan Specs Type

PWM

Operation MTBF

100,000 hours

Fan Specs Speed

3,500 ± 10% RPM

General Modular

Fully modular

General Wattage

850 W

Product Info EAN

5056547207377 (US) / 5056547207384 (EU) / 5056547207360 (UK) / 5056547207391 (JP)/ PS-8G1BB-AU (AU/NZ)

Product Info UPC

810074847414 (US) / 810074847421 (EU) / 810074847407 (UK) / 810074847438 (JP)/ PS-8G1BB-AU (AU/NZ)

Fan Specs Airflow

57 CFM

Fan Specs Bearing

Fluid dynamic bearing

General Cable Type

Individually embossed with cable comb

General Capacitors

All 105°C-rated Japanese

General ATX Version

3.1

General Form Factor

SFX

DC Output Rating 5VSB

3 A (15 W)

Fan Specs Noise Level

41 dBA

Operation Temperature

0 – 50°C

Product Info Warranty

10 years

DC Output Rating +12 V

70.83 A (850 W)

General 80 PLUS Rating

Gold

AC Input Rating Current

10 – 5 A

AC Input Rating Voltage

100 – 240 Vac

General Cybenetics Noise

A-

AC Input Rating Frequency

50 – 60 Hz

Product Info Model Number

PS-8G1BB-US / PS-8G1BB-EU / PS-8G1BB-UK / PS-8G1BB-JP / PS-8G1BB-AU

Energy Efficiency 20% Load

91.1% @ 115 V

Energy Efficiency 50% Load

92.1% @ 115 V

Energy Efficiency 100% Load

89.2% @ 115 V

Fan Specs Zero RPM Fan Mode

Yes

General Cybenetics Efficiency

Platinum

DC Output Rating +3.3 V and +5 V

20 A (100 W)

Energy Efficiency 80 PLUS Rating

Gold

Product Info Compliance Standard

ATX12V v3.1 / EPS12V v2.92

Electrical Features PF Correction

Active @ 0.97

Product Info Regulation & Certification

CE, UKCA, FCC, IC, BSMI, CB (IEC 62368-1 Ed. 3), LVD (EN 62368-1 Ed. 2), KC

Cable Length & Connector Quantity Peripherals Cable

100 + 100 + 100 mm (3)

Cable Length & Connector Quantity SATA Power Cables

100 + 100 + 100 mm (6)

Cable Length & Connector Quantity 24-pin ATX Power Cable

350 mm (1)

Cable Length & Connector Quantity 4+4-pin CPU Power Cable

470 mm (1)

Cable Length & Connector Quantity 6+2-pin PCIe Power Cable

470 mm (1)

Cable Length & Connector Quantity 16-pin (12+4) 12V-2x6 PCIe power cable

470 mm (1)

Cable Length & Connector Quantity 16-pin (PSU) to dual 8-pin (6+2) PCIe power cable

470 mm (2)
