Modulär

Full

Effekt

850 W

Dimensioner

150 × 150 × 86mm

Skydd

OVP (Over Voltage), UVP (Under Voltage), SCP (Short Circuit), OTP (Over Temperature), OPP (Over Power), OCP (Over Current)

Övriga specifikationer

Fan Specs Size

135 mm

Fan Specs Type

PWM

Operation MTBF

100,000 hours

Fan Specs Speed

2,300 ± 10% RPM

General Modular

Fully modular

General Wattage

850 W

Product Info EAN

5056547208695 (US) / 5056547208701 (EU) / 5056547208718 (UK) / 5056547208725 (JP) / 5056547208732 (AU)

Product Info UPC

810074849166 (US) / 810074849173 (EU) / 810074849180 (UK) / 810074849197 (JP) / 810074849203 (AU)

Fan Specs Airflow

103.36 CFM

Fan Specs Bearing

Fluid dynamic bearing

General Cable Type

Individually embossed with cable comb

General Capacitors

105°C performance capacitors

General ATX Version

3.1

General Form Factor

ATX

DC Output Rating 5VSB

3 A (15 W)

Fan Specs Noise Level

40.5 dBA

Operation Temperature

0 – 50°C (Continuous Full Load)

Product Info Warranty

7 years

DC Output Rating +12 V

70.8 A (850 W)

General 80 PLUS Rating

Gold

General Cybenetics Noise

A++

General Zero RPM Fan Mode

Yes

Product Info Model Number

PA-8G3BB-US / PA-8G3BB-EU / PA-8G3BB-UK / PA-8G3BB-JP / PA-8G3BB-AU

Energy Efficiency 10% Load

87% @ 115 V

Energy Efficiency 20% Load

91.58% @ 115 V

Energy Efficiency 50% Load

92.1% @ 115 V

Energy Efficiency 100% Load

89.33% @ 115 V

General Cybenetics Efficiency

Platinum

AC Input Rating 100 – 240 Vac

10 – 5 A, 50 – 60 Hz

DC Output Rating +3.3 V and +5 V

20 A (120 W)

Energy Efficiency 80 PLUS Rating

Gold

Product Info Compliance Standard

ATX12V v3.1 / EPS12V v2.92

Electrical Features PF Correction

Active @ 0.99

Product Info Regulation & Certification

CE, UKCA, FCC, IC, BSMI, CB (IEC 62368-1 Ed. 3), RCM, KC

AC Input Rating 200 – 240 Vac (South Korea)

5 A, 50 – 60 Hz

Cable Length & Connector Quantity SATA Cables

500 + 100 mm (8)

Cable Length & Connector Quantity Peripherals Cable

500 + 100 mm (3)

Cable Length & Connector Quantity 8-pin CPU Power Cable

700 mm (1)

Cable Length & Connector Quantity 24-pin ATX Power Cable

600 mm (1)

Cable Length & Connector Quantity 4+4-pin CPU Power Cable

700 mm (1)

Cable Length & Connector Quantity 6+2-pin PCIe Power Cable

650 mm (3)

Cable Length & Connector Quantity 16-pin (12+4) 12V-2x6 PCIe Power Cable

650 mm (1) (600W)
