Effekt

750 W

Dimensioner

150 × 140 × 86mm

Skydd

OVP, UVP, SCP, OTP, OPP, OCP

Övriga specifikationer

Fan Specs Size

120 mm

Fan Specs Type

PWM

Operation MTBF

100,000 hours

Fan Specs Speed

2,400 ± 10% RPM

General Modular

Non-modular

General Wattage

750 W

Product Info EAN

5056547207544 (US) / 5056547207551 (EU) / 5056547207568 (UK) / 5056547207520 (AU)

Product Info UPC

810074847711 (US) / 810074847728 (EU) / 810074847735 (UK) / 810074847698 (AU)

Fan Specs Airflow

64.4 CFM

Fan Specs Bearing

Fluid dynamic bearing

General Cable Type

Flat

General ATX Version

3.1

General Form Factor

ATX

DC Output Rating 5VSB

2.5 A (12.5 W)

Fan Specs Noise Level

39.92 dBA (max)

Operation Temperature

0 – 40°C

Product Info Warranty

5 years

DC Output Rating +12 V

62.5 A (750 W)

DC Output Rating -12 V

0.3 A (3.6 W)

Product Info Model Number

PA-7B3BB-US / PA-7B3BB-EU / PA-7B3BB-UK / PA-7B3BB-AU

Energy Efficiency 10% Loading

86.0% @ 115 V

Energy Efficiency 20% Loading

88.9% @ 115 V

Energy Efficiency 50% Loading

88.2% @ 115 V

General Bulk Capacitor Rating

105°C

Energy Efficiency 100% Loading

82.6% @ 115 V

AC Input Rating 100 – 240 Vac

10 – 5 A, 50 – 60 Hz

DC Output Rating +3.3 V and +5 V

20 A (120 W)

Energy Efficiency 80 PLUS Rating

Bronze

Product Info Compliance Standard

ATX12V v3.1 / EPS12V v2.92

Electrical Features PF Correction

Active @ 0.96

Product Info Regulation & Certification

CE, UKCA, FCC, IC, BIS, NOM, BSMI, CB (IEC 62368-1 Ed. 3), LVD (EN 62368-1 Ed. 2), RCM

Cable Length & Connector Quantity SATA Cable

500 + 150 mm (3)

Cable Length & Connector Quantity Peripherals Cable

500 + 150 mm (2)

Cable Length & Connector Quantity 8-pin CPU Power Cable

700 mm (1)

Cable Length & Connector Quantity 24-pin ATX Power Cable

600 mm (1)

Cable Length & Connector Quantity 4+4-pin CPU Power Cable

700 mm (1)

Cable Length & Connector Quantity 6+2-pin PCIe Power Cable

650 + 150 mm (2)

Cable Length & Connector Quantity 16-pin (12+4) 12V-2x6 PCIe Cable

650 mm (1)
