Fläktstorlek

135 mm

Modulär

Full

Effekt

1200 W

Garanti

10 years

ATX-version

ATX 3.1

Dimensioner

150 × 160 × 86mm

Effektivitet

80+ Gold

Formfaktor

ATX

Skydd

OVP / UVP / SCP / OTP / OPP / OCP

EPS-kontakter

2

SATA-kontakter

12

12VHPWR-kontakter

1

PCIe 8-pin-kontakter

3

Övriga specifikationer

EAN Black

5056547204604 (CN) / 5056547204611 (UK) / 5056547204628 (US) / 5056547204635 (EU) / 5056547204642 (JP) / 5056547204659 (AU)

EAN White

5056547206240 (CN) / 5056547206257 (UK) / 5056547206264 (US) / 5056547206271 (EU) / 5056547206288 (JP) / 5056547206295 (AU)

UPC Black

810074844673 (CN) / 810074844680 (UK) / 810074844697 (US) / 810074844703 (EU) / 810074844710 (JP) / 810074844727 (AU)

UPC White

810074846301 (CN) / 810074846318 (UK) / 810074846325 (US) / 810074846332 (EU) / 810074846349 (JP) / 810074846356 (AU)

Operation MTBF

100,000 hours

Fan Specs Noise

44.5 dBA max

Fan Specs Speed

2300 ± 10% RPM

Fan Specs Airflow

93.02 CFM (Min.)

Fan Specs Bearing

Fluid Dynamic Bearing (FDB)

Model Number Black

PA-2G2BB-CN / PA-2G2BB-UK / PA-2G2BB-US / PA-2G2BB-EU / PA-2G2BB-JP / PA-2G2BB-AU

Model Number White

PA-2G2BW-CN / PA-2G2BW-UK / PA-2G2BW-US / PA-2G2BW-EU / PA-2G2BW-JP / PA-2G2BW-AU

General Material(s)

Steel, PCB and Plastic

DC Output Rating 12V

100A (1200W)

DC Output Rating 5Vsb

3A (15W)

Operation Temperature

0 - 50 °C

Cable Specs SATA Cable

500 + 150mm

DC Output Rating 3.3V / +5V

22A (120W)

AC Input Rating 100 - 240Vac

14A 50Hz-60Hz

AC Input Rating 200 - 240Vac

7A 50Hz-60Hz (China & South Korea)

Cable Specs Peripherals Cable

500 + 150mm

Energy Efficiency 10% loading

85% @115Vac

Energy Efficiency 20% loading

90.1% @115Vac

Energy Efficiency 50% loading

91.6% @115Vac

Energy Efficiency 100% loading

88.7% @115Vac

Cable Specs 8-pin CPU Power Cable

700mm with nylon sleeving

Electrical Features PF Correction

Active @0.99

Cable Specs 24-pin ATX Power Cable

600mm with nylon sleeving

General Regulation & Certification

FCC, Canada, CE, CB(IEC 62368-1), UKCA, CCC, BSMI, BIS, RCM, UAE, TUV, cTUVus, KC, CP65

Cable Specs 4+4-pin CPU Power Cable

700mm with nylon sleeving

Output Connectors Peripherals Cable

4

Cable Specs 6+2-pin PCIe Power Cable

650mm with nylon sleeving

Output Connectors 24-pin ATX Power Cable

1

Cable Specs 16-pin (12+4) 12V-2x6 PCIe Cable

650mm with nylon sleeving
