Fläktstorlek

135 mm

Modulär

Full

Effekt

1000 W

Garanti

10 years

ATX-version

ATX 3.1

Dimensioner

150 × 160 × 86mm

Effektivitet

80+ Gold

Formfaktor

ATX

Skydd

OVP / UVP / SCP / OTP / OPP / OCP

EPS-kontakter

2

SATA-kontakter

12

12VHPWR-kontakter

1

PCIe 8-pin-kontakter

3

Övriga specifikationer

EAN Black

5056547204680 (CN) / 5056547204697 (UK) / 5056547204703 (US) / 5056547204710 (EU) / 5056547204727 (JP) / 5056547204734 (AU)

EAN White

5056547206318 (CN) / 5056547206325 (UK) / 5056547206332 (US) / 5056547206349 (EU) / 5056547206356 (JP) / 5056547206363 (AU)

UPC Black

810074844758 (CN) / 810074844765 (UK) / 810074844772 (US) / 810074844789 (EU) / 810074844796 (JP) / 810074844802 (AU)

UPC White

810074846370 (CN) / 810074846387 (UK) / 810074846394 (US) / 810074846400 (EU) / 810074846417 (JP) / 810074846424 (AU)

Operation MTBF

100,000 hours

Fan Specs Noise

44.5 dBA max

Fan Specs Speed

2300 ± 10% RPM

Fan Specs Airflow

93.02 CFM (Min.)

Fan Specs Bearing

Fluid Dynamic Bearing (FDB)

Model Number Black

PA-0G2BB-CN / PA-0G2BB-UK / PA-0G2BB-US / PA-0G2BB-EU / PA-0G2BB-JP / PA-0G2BB-AU

Model Number White

PA-0G2BW-CN / PA-0G2BW-UK / PA-0G2BW-US / PA-0G2BW-EU / PA-0G2BW-JP / PA-0G2BW-AU

General Material(s)

Steel, PCB and Plastic

DC Output Rating 12V

83.3A (1000W)

DC Output Rating 5Vsb

3A (15W)

Operation Temperature

0 - 50 °C

Cable Specs SATA Cable

500 + 150mm

DC Output Rating 3.3V / +5V

22A (120W)

AC Input Rating 100 - 240Vac

13A 50Hz-60Hz

AC Input Rating 200 - 240Vac

6.5A 50Hz-60Hz (China & South Korea)

Cable Specs Peripherals Cable

500 + 150mm

Energy Efficiency 10% loading

85.5% @115Vac

Energy Efficiency 20% loading

89.7% @115Vac

Energy Efficiency 50% loading

91.9% @115Vac

Energy Efficiency 100% loading

89.3% @115Vac

Cable Specs 8-pin CPU Power Cable

700mm with nylon sleeving

Electrical Features PF Correction

Active @0.99

Cable Specs 24-pin ATX Power Cable

600mm with nylon sleeving

General Regulation & Certification

FCC, Canada, CE, CB(IEC 62368-1), UKCA, CCC, BSMI, BIS, RCM, UAE, TUV, cTUVus, KC, CP65

Cable Specs 4+4-pin CPU Power Cable

700mm with nylon sleeving

Output Connectors Peripherals Cable

4

Cable Specs 6+2-pin PCIe Power Cable

650mm with nylon sleeving

Output Connectors 24-pin ATX Power Cable

1

Cable Specs 16-pin (12+4) 12V-2x6 PCIe Cable

650mm with nylon sleeving
