5 mA max. / measured between lead wire (+) and frame at 500 VAC/min5 mA max. / measured between lead wire (+) and frame at 500 VAC/min
Input current (max)
0.04 A0.04 A
Motor type (phases)
Single phaseSingle phase
Polarity protection
Open circuit when Vcc & GND are exchanged. Circuit won't be burned within 5 sec when Vcc & GND are exchanged.Open circuit when Vcc & GND are exchanged. Circuit won't be burned within 5 sec when Vcc & GND are exchanged.
Storage temperature
-20°C to +75°C-20°C to +75°C
Production standards
ISO 9001 & ISO 14001ISO 9001 & ISO 14001
Rotational direction
Counter-clockwiseCounter-clockwise
Input power (typical)
0.32 W0.32 W
Insulation resistance
10 MΩ / between unshielded wire and frame at 500 VDC/min10 MΩ / between unshielded wire and frame at 500 VDC/min
Operating temperature
-10°C to +70°C-10°C to +70°C
Max. operating voltage
13.2 V13.2 V
Input current (typical)
0.03 A0.03 A
Locked rotor protection
Auto power off after locked at rated voltage for 1 sec. After auto power off, the circuit attempts to restart in 2 to 6 sec.Auto power off after locked at rated voltage for 1 sec. After auto power off, the circuit attempts to restart in 2 to 6 sec.
