120 x 120 x 25 mm (square)120 x 120 x 25 mm (square)
Dielectric strength
5 mA max. / measured between lead wire (+) and frame at 500 VAC/min5 mA max. / measured between lead wire (+) and frame at 500 VAC/min
Input current (max)
0.15 A0.15 A
Motor type (phases)
Single phaseSingle phase
Polarity protection
Open circuit when Vcc & GND are exchanged. Circuit won't be burned within 5 sec when Vcc & GND are exchanged.Open circuit when Vcc & GND are exchanged. Circuit won't be burned within 5 sec when Vcc & GND are exchanged.
Storage temperature
-20°C to +65°C-20°C to +65°C
Production standards
ISO 9001 & ISO 14001ISO 9001 & ISO 14001
Rotational direction
Counter-clockwiseCounter-clockwise
Insulation resistance
10 MΩ / between unshielded wire and frame at 500 VDC/min10 MΩ / between unshielded wire and frame at 500 VDC/min
Operating temperature
-10°C to +60°C-10°C to +60°C
Max. operating voltage
13.2 V13.2 V
Airflow with LNA (max.)
87.2 m³/h (51.32 CFM)87.2 m³/h (51.32 CFM)
Locked rotor protection
Auto power off after locked at rated voltage for 1 sec. After auto power off, the circuit attempts to restart in 2 to 6 sec.Auto power off after locked at rated voltage for 1 sec. After auto power off, the circuit attempts to restart in 2 to 6 sec.
