AC2200 LTE Mesh Router (LBR20)

WiFi

WiFi 5

5 GHz

Nej

6 GHz

Nej

Ethernet

1 Gbps

2,4 GHz

Nej

Externa antenner

2

Mobilnät

4G

Övriga specifikationer

Ports

Two (2) external SMA type antenna ports (antenna not included), Two (2) 10/100/1000Mbps Gigabit Ethernet ports (1 WAN + 1 LAN)

Support

24/7 basic technical support provided for 90 days from purchase date, when purchased from a NETGEAR authorised reseller. / Support

Antennas

Two (2) external SMA type antenna ports (antenna not included), Two (2) 10/100/1000Mbps Gigabit Ethernet ports (1 WAN + 1 LAN) / One (1) Orbi LTE Router (LBR20) / One (1) 2m Ethernet cable / One (1) 12V/2.5A power adapter / Quick start guide

SIM Slot

Two (2) external SMA type antenna ports (antenna not included), Two (2) 10/100/1000Mbps Gigabit Ethernet ports (1 WAN + 1 LAN)

Security

Advanced cyber threat protection for your PC, Mac and mobile devices with NETGEAR Armor Standards-based WiFi Security (802.11i, 128-bit AES encryption with PSK), Guest WiFi Network is easy to setup separate & secure Internet access for guests, Circle Smart Parental Controls to manage content and time online for all your devices.

Warranty

This product is backed by a NETGEAR limited 1-year Hardware Warranty. / †Maximum wireless signal rate derived from IEEE 802.11 specifications. Actual data throughput and wireless coverage will vary and be lowered by network and environmental conditions, including network traffic volume, device limitations, and building construction. NETGEAR makes no representations or warranties about this product’s compatibility with future standards. Up to 2,200Mbps wireless speeds achieved when connecting to other 802.11ac 2,200Mbps devices. / †† Network must support subset of the 4G LTE bands listed under the Technical Specifications.

Interface

Two (2) external SMA type antenna ports (antenna not included), Two (2) 10/100/1000Mbps Gigabit Ethernet ports (1 WAN + 1 LAN)

Dimensions

6.7 x 3.1 x 8.9in

Interfaces

Two (2) external SMA type antenna ports (antenna not included), Two (2) 10/100/1000Mbps Gigabit Ethernet ports (1 WAN + 1 LAN)

LTE Support

Built in 4G LTE Modem. LTE Category 18, capable of up to 1.2 Gbps. 4G LTE Band (LTE FDD): B2,4,5,7,12,13,14,17,25,26,29,30,66,71. 4G Band (LTE-TDD): B41. 3G Band: B1,4,5

Network Type

AC2200 LTE Mesh Router (LBR20)

Wi-Fi Speeds

AC2200 LTE Mesh Router (LBR20)

WiFi Coverage

125 m2

What's in the box

One (1) Orbi LTE Router (LBR20) / One (1) 2m Ethernet cable / One (1) 12V/2.5A power adapter / Quick start guide

Dedicated Backhaul

2X2 (866Mbps), 5GHz (866Mbps†) dedicated WiFi link for faster data connections between Orbi Router and (additional) Orbi Satellite

AC2200 Tri-Band WiFi

2.4GHz (400Mbps†) + 5GHz (866Mbps†) for WiFi devices to connect to the Internet

Orbi 4G LTE Advanced Router (AC2200)

Implicit & Explicit Beamforming for 2.4GHz & 5GHz bands, MU-MIMO capable for simultaneous data streaming to multiple devices, Powerful Quad-Core 710MHz processor

Works with Amazon Alexa and the Google Assistant

Yes
