1x HDMI port, supports a maximum resolution of 4096x2160 @ 30Hz; 1x DisplayPort port supports a maximum resolution of 4096 x 2304 @ 60Hz
Övriga specifikationer
USB
2x USB 3.2 Gen 2 10Gbps ports (1 Type-A port and 1 Type-C port on the back panel); 7x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 4 ports through the internal USB connectors, 1 Type-C internal connector); 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors)
HDMI
1
RAID
0/1/5/10
Socket
1200
DirectX
12
SATAIII
6
M.2 Slot
2
Mounting
9 mounting holes
PCI-E x1
3
CrossFire
Y
Multi-GPU
Supports 2-Way AMD CrossFire Technology
PCI-E Gen
Gen3
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
PCI-E x16
2
Processor
Please go to intel.com for compatibility information.; Onboard graphics output are disabled when using the F SKU processors.; BIOS updated to be compatible with 11th Gen Intel Core Processors
DIMM Slots
4
Dimensions
ATX Form Factor; 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 10 64-bit
DisplayPort
1
Form Factor
ATX
TPM (header)
1
Expansion Slot
1x PCIe 3.0 x16 slot (from CPU) Support up to PCIe 4.0 for 11th Gen Intel CPU Support up to PCIe 3.0 for 10th Gen Intel CPU; 1x PCIe 3.0 x16 slot (from chipset, supports x4 mode); 3x PCIe x1 slots (from chipset)
Memory Channel
Dual
Max Memory (GB)
128
Back panel ports
Keyboard / Mouse; 2.5G LAN; Audio Connectors; USB 2.0; HDMI; DisplayPort; USB 3.2 Gen 2 10Gbps Type-A + Type-C; USB 3.2 Gen 1 5Gbps Type-A
Operating System
Support for Windows 10 64-bit
Audio ports (Rear)
Realtek ALC892/ALC897 Codec
Internal connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 1x 4-pin ATX 12V power connector; 6x SATA 6Gb/s connectors; 1x USB 3.2 Gen 1 5Gbps Type-C port; 2x USB 3.2 Gen 1 5Gbps connectors (support additional 4 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors (support additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water pump connector; 6x 4-pin system fan connectors; 1x front panel audio connector; 2x system panel connectors; 1x Chassis Intrusion connector; 1x Clear CMOS jumper; 1x 4-pin RGB LED connector; 2x 3-pin RAINBOW LED connectors; 1x serial port connector; 1x TPM module connector; 1x TBT connector 1; Thunderbolt card need support RTD3
Serial ports(Front)
1
USB 2.0 ports (Rear)
2
USB 3.2 ports (Rear)
1(Gen 2, Type C), 1(Gen 2, Type A), 2(Gen 1, Type A)
