1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz 12; 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz 12; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
USB
Intel Z690 Chipset 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel 2x USB 3.2 Gen 2 10Gbps ports (1 Type-C internal connector and 1 Type-A port on the back panel) 6x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, and 4 ports are available through the internal USB connectors) 4x USB 2.0 Type-A ports on the back panel; 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel; 2x USB 3.2 Gen 2 10Gbps ports (1 Type-C internal connector and 1 Type-A port on the back panel); 6x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, and 4 ports are available through the internal USB connectors); 4x USB 2.0 Type-A ports on the back panel; USB Hub GL850G 4x USB 2.0 ports are available through the internal USB connectors; 4x USB 2.0 ports are available through the internal USB connectors
HDMI
1
RAID
0/1/5/10
Socket
1700
DirectX
12
SATAIII
6
M.2 Slot
4
Mounting
9 mounting holes
PCI-E x1
1
CrossFire
Y
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
Dimension
12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Multi-GPU
Supports AMD CrossFire Technology
PCI-E x16
3
Processor
Please go to intel.com for compatibility information
DIMM Slots
4
Dimensions
ATX Form Factor; 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
1x 4-pin RGB LED connector; 2x 3-pin RAINBOW LED connectors; 4x EZ Debug LED
TPM (header)
1
Expansion Slot
3x PCIe x16 slots PCI_E1 (from CPU) Supports up to PCIe 5.0 x16 PCI_E3 & PCI_E4 (from Z690 chipset) Supports up to PCIe 3.0 x4 & 3.0 x1; PCI_E1 (from CPU) Supports up to PCIe 5.0 x16; Supports up to PCIe 5.0 x16; PCI_E3 & PCI_E4 (from Z690 chipset) Supports up to PCIe 3.0 x4 & 3.0 x1; Supports up to PCIe 3.0 x4 & 3.0 x1; 1x PCIe 3.0 x1 slot (from Z690 chipset)
Memory Channel
Dual
Max Memory (GB)
192
Back panel ports
Keyboard / Mouse; DisplayPort; USB 2.0; LAN port; WIFI / Bluetooth; Audio connector; Flash BIOS Button; USB 2.0; HDMI; USB 3.2 Gen 1 5Gbps Type-A; USB 3.2 Gen 2x2 20Gbps Type-C; USB 3.2 Gen 2 10Gbps Type-A
Operating System
Support for Windows 11 64-bit, Windows 10 64-bit
WiFi & Bluetooth
Intel Wi-Fi 6E module
Audio ports (Rear)
Realtek ALC897 Codec
Internal connectors
1x 24-pin ATX main power connector; 2x 8-pin ATX 12V power connector; 6x SATA 6Gb/s connectors; 4x M.2 slots (M-Key); 1x USB 3.2 Gen 2 10Gbps Type-C port; 2x USB 3.2 Gen 1 5Gbps connectors (supports additional 4 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 6x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x Clear CMOS jumper; 1x TPM module connector; 1x Tuning controller connector; 1x TBT connector (Supports RTD3)
USB 2.0 ports (Rear)
4
USB 3.2 ports (Rear)
1(Gen 2x2, Type C), 1(Gen 2, Type A), 2(Gen 1, Type A)
