1x HDMI 1.4 with HDR port, supporting a maximum resolution of 4K 30Hz 1 / 2; 1x VGA port, supporting a maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz 1 / 2; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
VGA
1
HDMI
1
Socket
1700
Recensioner
Laddar recensioner…
DirectX
12
Jumpers
1x Clear CMOS jumper
SATAIII
4
M.2 Slot
1
PCI-E x1
1
PCI-E x16
1
Processor
Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors 1; Processor socket LGA1700; Please go to www.msi.com to get the newest support status as new processors are released.
DIMM Slots
2
Dimensions
M-ATX Form Factor; 9.3 in. x 7.9 in. (23.6 cm x 20 cm)
SATA Ports
4x SATA 6Gb/s ports (From H610 chipset)
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 11 64-bit, Windows 10 64-bit
Form Factor
Mirco-ATX
LED Features
1x 4-pin RGB LED connector; 4x EZ Debug LED
M.2 SSD Slot
1x M.2 slot (Key M) (from H610 chipset) Supports up to PCIe 3.0 x4 Supports up to SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices; Supports up to PCIe 3.0 x4; Supports up to SATA 6Gb/s; Supports 2242/ 2260/ 2280 storage devices
TPM (header)
1
Expansion Slot
1x PCIe x16 slot (From CPU) Supports up to PCIe 4.0 x16; Supports up to PCIe 4.0 x16; 1x PCIe x1 slot (From H610 chipset) Supports PCIe 3.0 x1; Supports PCIe 3.0 x1
Fan Connectors
1x 4-pin CPU fan connector; 2x 4-pin system fan connectors
Memory Channel
Dual
Max Memory (GB)
64
Back panel ports
HDMI; VGA; Keyboard / Mouse; USB 3.2 Gen 1 5Gbps Type-A; LAN port; Audio connector; USB 2.0
Power Connectors
1x 24-pin ATX main power connector; 1x 8-pin +12V power connector
System Connectors
1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x TPM module connector; 1x Serial port connector
Audio ports (Rear)
Realtek ALC897 Codec
USB 2.0 ports (Rear)
4
USB 3.2 ports (Rear)
2(Gen 1, Type A)
USB 2.0 ports (Front)
4
USB 3.2 ports (Front)
2(Gen 1, Type A)
Internal USB Connectors
1x USB 3.2 Gen 1 5Gbps connector (From H610 chipset) Supports additional 2 USB 3.2 Gen 1 5Gbps ports; Supports additional 2 USB 3.2 Gen 1 5Gbps ports; 2x USB 2.0 Type-A connectors (From Hub-GL850G) Supports additional 4 USB 2.0 ports; Supports additional 4 USB 2.0 ports
