1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz 1 / 2; 1x VGA port, supports a maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz 1 / 2; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
USB
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector); 6x USB 2.0 ports (4 Type-A ports on the back panel(hub-GL850G), 2 ports available through the internal USB 2.0 connector)
VGA
1
HDMI
1
Socket
1700
DirectX
12
Jumpers
1x Clear CMOS jumper
SATAIII
4
M.2 Slot
1
PCI-E x1
1
PCI-E x16
1
Processor
Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors 1; Processor socket LGA1700; Please go to www.msi.com to get the newest support status as new processors are released.
DIMM Slots
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
2
Dimensions
M-ATX Form Factor; 9.3 in. x 8.0 in. (24.4 cm x 21.1 cm)
SATA Ports
4x SATA 6Gb/s ports1; SATA7 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 11 64-bit, Windows 10 64-bit
Form Factor
Mirco-ATX
LED Features
4x EZ Debug LED
M.2 SSD Slot
1x M.2 slot (Key M, from chipset) 1 Supports up to PCIe 3.0 x4 Supports up to SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices Supports Intel Smart Response Technology for Intel Core processors; Supports up to PCIe 3.0 x4; Supports up to SATA 6Gb/s; Supports 2242/ 2260/ 2280 storage devices; Supports Intel Smart Response Technology for Intel Core processors; SATA7 will be unavailable when installing M.2 SATA SSD in the M2_1 slot
TPM (header)
1
Expansion Slot
1x PCIe x16 slot (From CPU) Supports up to PCIe 4.0 x16; Supports up to PCIe 4.0 x16; 1x PCIe x1 slot Supports PCIe 3.0 x1; Supports PCIe 3.0 x1; 1x M.2 slot with E-key for PCIe WiFi module only (M2_WIFI1)
Fan Connectors
1x 4-pin CPU fan connector; 1x 4-pin System fan connector
Memory Channel
Dual
Max Memory (GB)
64
Back panel ports
HDMI; VGA; Keyboard/Mouse; USB 3.2 Gen 1 5Gbps Type-A; LAN port; Audio connector; USB 2.0
Power Connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector
System Connectors
1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x TPM module connector; 1x Serial port connector
