1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz1/ 2; 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz1/ 2; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
USB
1x USB3.2 Gen2x2 20Gbps port (Type-C port on the back panel); 4x USB 3.2 Gen 2 10Gbps ports (3 Type-A port on the back panel, 1 Type-C available through the internal connector); 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 Type-A ports available through the internal connector); 8x USB 2.0 ports (4 Type-A ports on the back panel, 4 Type-A ports available through internal connectors)
HDMI
1
RAID
0/1/5/10
Socket
1200
DirectX
12
SATAIII
6
M.2 Slot
3
Mounting
9 mounting holes
PCI-E x1
2
CrossFire
Y
Multi-GPU
Supports 3-Way AMD CrossFire Technology
PCI-E x16
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
3
Processor
Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors 1; Processor socket LGA1200; Please go to intel.com for compatibility information.
DIMM Slots
4
Dimensions
ATX Form Factor; 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 10 64-bit
DisplayPort
1
Form Factor
ATX
LED Feature
1x EZ LED Control switch; 4x EZ Debug LED; 1x 2-Digit Debug Code LED; 1x 4-pin RGB LED connector; 2x 3-pin RAINBOW LED connectors; 1x 3-pin CORSAIR LED connector
Memory Channel
Dual
Expansion Slots
3x PCIe x16 slots Support x16/x0/x4, x8/x8/x4, x8/x4+x4/x4 PCI_E1 & PCI_E3 slots (From CPU) Support PCIe 4.0 for 11th Gen Intel CPU Support PCIe 3.0 for 10th Gen Intel CPU PCI_E5 slot (From Z590 Chipset) Supports PCIe 3.0; Support x16/x0/x4, x8/x8/x4, x8/x4+x4/x4; PCI_E1 & PCI_E3 slots (From CPU) Support PCIe 4.0 for 11th Gen Intel CPU Support PCIe 3.0 for 10th Gen Intel CPU; Support PCIe 4.0 for 11th Gen Intel CPU; Support PCIe 3.0 for 10th Gen Intel CPU; PCI_E5 slot (From Z590 Chipset) Supports PCIe 3.0; Supports PCIe 3.0; 2x PCIe 3.0 x1 slots (From Z590 Chipset)
Max Memory (GB)
128
Back panel ports
USB 2.0; DisplayPort; USB 3.2 Gen 1 5Gbps Type-A; 2.5G LAN; Audio Connectors; Flash BIOS Button; HDMI; USB 3.2 Gen 2 10Gbps Type-A; USB 3.2 Gen 2x2 20Gbps Type-C; Wi-Fi / Bluetooth; Optical S/PDIF Out
Operating System
Support for Windows 10 64-bit
WiFi & Bluetooth
Intel Wi-Fi 6E AX210
Audio ports (Rear)
5+ Optical S/PDIF (Realtek ALC4080 Codec)
Internal connectors
1x 24-pin ATX main power connector; 2x 8-pin ATX 12V power connectors; 1x 6-pin PCIE power connector; 6x SATA 6Gb/s connectors; 3x M.2 slots (M-Key); 1x USB 3.2 Gen 2 10Gbps Type-C port; 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 Type-A connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 6x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x Clear CMOS jumper; 1x TPM module connector; 1x TBT connector (supports RTD3); 1x Tuning Controller connector
USB 2.0 ports (Rear)
4
USB 3.2 ports (Rear)
1(Gen 2x2, Type C), 3(Gen 2, Type A), 2(Gen 1, Type A)
