- USB
- 4x USB 2.0 (Front) 4x USB 5Gbps Type A (Front) 9x USB 10Gbps Type A (Rear) 2x USB 10Gbps Type C (Rear) 1x USB 20Gbps Type C (Front) 2x USB 40Gbps Type C (Rear)
- RAID
- •Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices •Supports RAID 0, RAID 1, RAID 5 and RAID 10* for M.2 NVMe storage devices *RAID 5/ 10 configuration is only supported by Ryzen 9000/7000 series processors.
- Mounting
- 9 mounting holes
- Multi-GPU
- Supports AMD CrossFire Technology
- Processor
- Supports 12th Gen Intel Core, Pentium Gold and Celeron Processors 1; Processor socket LGA1700; Please go to intel.com for compatibility information.
- Dimensions
- ATX Form Factor; 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
- Box content
- MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
- Internal IO
- 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 5x System Fan 1x EZ Conn-header (JAF_2) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Thermal Sensor connectors(T_SEN) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports
- LED FEATURE
- 4x EZ Debug LED 1x EZ Digit Debug LED
- Expansion Slots
- 3x PCIe x16 slots PCI_E1 & PCI_E2 slots (From CPU) Support PCIe 5.0 Support x16/ x0, x8/ x8 PCI_E3 slot (From Z690 Chipset) Supports PCIe 3.0 x4; PCI_E1 & PCI_E2 slots (From CPU) Support PCIe 5.0 Support x16/ x0, x8/ x8; Support PCIe 5.0; Support x16/ x0, x8/ x8; PCI_E3 slot (From Z690 Chipset) Supports PCIe 3.0 x4; Supports PCIe 3.0 x4
- BACK PANEL PORTS
- USB 10Gbps Type-A Flash BIOS Button Clear CMOS Button Smart Button 2.5G LAN 5G LAN Audio Connectors HDMI USB 40Gbps Type-C USB 10Gbps Type-C USB 10Gbps Type-A USB 10Gbps Type-C Wi-Fi / Bluetooth Optical S/PDIF Out
- OPERATING SYSTEM
- Support for Windows 11 64-bit
- WiFi & Bluetooth
- The Wireless module is pre-installed in the M.2 (Key-E) slot; Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/6GHz 1(160MHz) up to 2.4Gbps; Supports 802.11 a/ b/ g/ n/ ac/ ax; Supports Bluetooth 5.22, FIPS, FISMA; Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in WIN10 21H1 and Windows 11.; Bluetooth 5.2 will be ready in WIN10 21H1 and Windows11.
- Internal connectors
- 1x 24-pin ATX main power connector; 2x 8-pin ATX 12V power connectors; 6x SATA 6Gb/s connectors; 5x M.2 slots (M-Key); 1x USB 3.2 Gen 2 10Gbps Type-C connector; 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 Type-A connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 6x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x Clear CMOS jumper; 1x TPM module connector; 1x TBT connector (supports RTD3); 1x Tuning Controller connector
