1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz 1 / 2; 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz 1 / 2; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
USB
1x USB3.2 Gen2x2 20Gbps Type-C port on the back panel; 2x USB 3.2 Gen 2 10Gbps ports (1 Type-C internal connector and 1 Type-A port on the back panel); 6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 ports through the internal connector); 1x USB 2.0 Type-A port on the back panel; 5x USB 2.0 ports (1 Type-A port on the back panel, 4 Type-A ports available through internal connectors)
HDMI
1
RAID
0/1/5/10
Socket
1200
DirectX
12
SATAIII
6
M.2 Slot
3
PCI-E x1
2
CrossFire
Y
Multi-GPU
Supports 2-Way AMD CrossFire Technology
PCI-E x16
2
Processor
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
Supports 10th Gen Intel Core, 11th Gen Intel Core, Pentium Gold and Celeron processors 1; Processor socket LGA1200; Please go to intel.com for compatibility information.
DIMM Slots
4
Dimensions
ATX Form Factor; 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 10 64-bit
DisplayPort
1
Form Factor
ATX
LED Feature
1x EZ LED Control switch; 2x 4-pin RGB LED connectors; 2x 3-pin RAINBOW LED connectors; 4x EZ Debug LED
Expansion Slot
2x PCIe x16 slots 1x PCIe 3.0 x16 slot (from CPU) Support up to PCIe 4.0 for 11th Gen Intel CPU Support up to PCIe 3.0 for 10th Gen Intel CPU PCI_E3 (From Z590 chipset) Support up to PCIe 3.0 x4; 1x PCIe 3.0 x16 slot (from CPU) Support up to PCIe 4.0 for 11th Gen Intel CPU Support up to PCIe 3.0 for 10th Gen Intel CPU; Support up to PCIe 4.0 for 11th Gen Intel CPU; Support up to PCIe 3.0 for 10th Gen Intel CPU; PCI_E3 (From Z590 chipset) Support up to PCIe 3.0 x4; Support up to PCIe 3.0 x4; 2x PCIe 3.0 x1 slots (From Z590 chipset)
Memory Channel
Dual
Max Memory (GB)
128
Back panel ports
DisplayPort; USB 2.0; USB 3.2 Gen 1 5Gbps Type-A; 2.5G LAN Port; Wi-Fi / Bluetooth Antenna; HD Audio Connectors; HDMI; Flash BIOS Button; USB 3.2 Gen 1 5Gbps Type-A; USB 3.2 Gen 2 10Gbps Type-A; USB 3.2 Gen 2x2 20Gbps Type-C; Optical S/PDIF OUT
Operating System
Support for Windows 10 64-bit
WiFi & Bluetooth
Intel Wi-Fi 6E AX210
Audio ports (Rear)
5+ Optical S/PDIF (Realtek ALC4080 Codec)
Internal connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 1x 4-pin ATX 12V power connector; 1x 6-pin PCIE power connector; 6x SATA 6Gb/s connectors; 3x M.2 slots (M-Key); 1x USB 3.2 Gen 2 10Gbps Type-C port; 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 Type-A connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 6x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x TPM module connector; 1x Clear CMOS jumper; 1x TBT connector (supports RTD3); 1x Tuning Controller connector
USB 2.0 ports (Rear)
2
USB 3.2 ports (Rear)
1(Gen 2x2, Type C), 1(Gen 2, Type A), 4(Gen 1, Type A)
