1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz1 / 2; 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz1 / 2; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
USB
1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel; 2x USB 3.2 Gen 2 10Gbps ports (1 Type-C internal connector and 1 Type-A port on the back panel); 4x USB 3.2 Gen 1 5Gbps ports are available through the internal USB connectors); 6x USB 2.0 Type-A ports on the back panel; 4x USB 2.0 ports are available through the internal USB connectors
HDMI
1
RAID
0/1/5/10
Socket
1700
DirectX
12
SATAIII
6
M.2 Slot
3
PCI-E x1
1
CrossFire
Y
Multi-GPU
Supports AMD CrossFire Technology
PCI-E x16
3
PROCESSOR
Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors 1; Processor socket LGA1700; Please go to www.msi.com to get the newest support status as new processors are released.
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
DIMM Slots
4
Dimensions
ATX Form Factor; 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 11 64-bit, Windows 10 64-bit
DisplayPort
1
Form Factor
ATX
LED Feature
1x 4-pin RGB LED connector; 2x 3-pin RAINBOW LED connectors; 4x EZ Debug LED
Expansion Slot
3x PCIe x16 slots PCI_E1 (From CPU) Support up to PCIe 5.0 x16 PCI_E3 & PCI_E4 (From H670 chipset) Support PCIe 3.0 x4 & 3.0 x1; PCI_E1 (From CPU) Support up to PCIe 5.0 x16; Support up to PCIe 5.0 x16; PCI_E3 & PCI_E4 (From H670 chipset) Support PCIe 3.0 x4 & 3.0 x1; Support PCIe 3.0 x4 & 3.0 x1; 1x PCIe 3.0 x1 slot (Fom H670 chipset)
Memory Channel
Dual
Max Memory (GB)
128
Back panel ports
Keyboard / Mouse; DisplayPort 1.4; USB 2.0; 2.5G LAN Port; Wi-Fi / Bluetooth; Audio Connectors; Flash BIOS Bottom; USB 2.0; HDMI 2.1 Port; USB 3.2 Gen 2x2 20Gbps Type-C; USB 3.2 Gen 2 10Gbps Type-A
WiFi & Bluetooth
Intel Wi-Fi 6 module
Audio ports (Rear)
Realtek ALC897 Codec)
Internal connectors
1x 24-pin ATX main power connector; 2x 8-pin ATX 12V power connector; 6x SATA 6Gb/s connectors; 3x M.2 slots (M-Key); 1x USB 3.2 Gen 2 10Gbps Type-C port; 2x USB 3.2 Gen 1 5Gbps connectors (supports additional 4USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 6x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x Clear CMOS jumper; 1x TPM module connector; 1x Tuning controller connector; 1x TBT connector (Supports RTD3)
USB 2.0 ports (Rear)
6
USB 3.2 ports (Rear)
1(Gen 2x2, Type C), 1(Gen 2, Type A)
USB 2.0 ports (Front)
4
USB 3.2 ports (Front)
1(Gen 2, Type C), 2(Gen 1, Type A), 4(Gen 1, Type A)
