1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz 1 / 2; 1x DisplayPort 1.4 port with HBR3, supports a maximum resolution of 4K 60Hz 1 / 2; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
USB
1x USB3.2 Gen 2x2 20Gbps port (Type-C port on the back panel); 5x USB 3.2 Gen 2 10Gbps ports (4 Type-A ports on the back panel, 1 Type-C available through the internal connector); 2x USB 3.2 Gen 1 5Gbps Type-A ports available through the internal connector; 8x USB 2.0 ports (4 Type-A ports on the back panel, 4 Type-A ports available through the internal connectors)
HDMI
1
RAID
0/1/5/10
Socket
1700
DirectX
12
SATAIII
6
M.2 Slot
3
PCI-E x1
1
CrossFire
Y
Multi-GPU
Supports AMD CrossFire Technology
PCI-E x16
2
Processor
Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors 1; Processor socket LGA1700; Please go to msi.com to get the newest support status as new processors are released.
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
DIMM Slots
4
Dimensions
ATX Form Factor; 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
2x 4-pin RGB LED connectors; 2x 3-pin RAINBOW LED connectors; 4x EZ Debug LED
Expansion Slot
2x PCIe x16 slots PCI_E1 (From CPU) Support up to PCIe 4.0 PCI_E2 (From B660 chipset) Support up to PCIe 3.0 x4; PCI_E1 (From CPU) Support up to PCIe 4.0; Support up to PCIe 4.0; PCI_E2 (From B660 chipset) Support up to PCIe 3.0 x4; Support up to PCIe 3.0 x4; 1x PCIe 3.0 x1 slot (From B660 chipset)
Memory Channel
Dual
Max Memory (GB)
192
Back panel ports
USB 2.0 Port; DisplayPort 1.4; 2.5G LAN Port; Wi-Fi / Bluetooth Antenna; HD Audio Connectors; HDMI 2.1 Port; USB 3.2 Gen 2 10Gbps Type-A; USB 3.2 Gen 2x2 20Gbps Type-C; Optical S/PDIF OUT
WiFi & Bluetooth
Intel Wi-Fi 6E module
Audio ports (Rear)
Realtek ALC1220P Codec
Internal connectors
1x 24-pin ATX main power connector; 2x 8-pin ATX 12V power connectors; 6x SATA 6Gb/s connectors; 3x M.2 slots (M-Key); 1x USB 3.2 Gen 2 10Gbps Type-C port; 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 5x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x Clear CMOS jumper; 1x TPM module connector; 1x TBT connector (supports RTD3); 1x Tuning Controller connecto
