1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz12; 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz12; Available only on processors featuring integrated graphics; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
USB
1x USB3.2 Gen 2x2 20Gbps port (Type-C port on the back panel); 1x USB 3.2 Gen 2 10Gbps port (1 Type-C available through the internal connector); 6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 Type-A ports available through the internal connector); 4x USB 2.0 ports on the back panel; 4x USB 2.0 ports available through the internal connectors
HDMI
1
Socket
1200
SATAIII
6
M.2 Slot
3
PCI-E x1
1
CrossFire
Y
Multi-GPU
Supports 2-Way AMD CrossFire Technology
PCI-E x16
2
Processor
Please go to intel.com for compatibility information.
DIMM Slots
4
CPU Support
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
Support for Windows 10 64-bit
DisplayPort
1
Form Factor
ATX
LED Feature
1x EZ LED Control switch; 2x 4-pin RGB LED connectors; 2x 3-pin RAINBOW LED connectors; 4x EZ Debug LED
Expansion Slot
2x PCIe x16 slots; PCI_E1 (from CPU); Support up to PCIe 4.0 for 11th Gen Intel CPU; Support up to PCIe 3.0 for 10th Gen Intel CPU; PCI_E2 (from B560 chipset); Support up to PCIe 3.0 x4; 1x PCIe 3.0 x1 slot (from B560 chipset)
Memory Channel
Dual
Max Memory (GB)
128
Back panel ports
USB 2.0; DisplayPort; 2.5G LAN Port; Wi-Fi / Bluetooth Antenna; HD Audio Connectors; HDMI; USB 3.2 Gen 1 5Gbps Type-A; USB 3.2 Gen 1 5Gbps Type-A; USB 3.2 Gen 2x2 20Gbps Type-C; Optical S/PDIF OUT
WiFi & Bluetooth
Intel Wi-Fi 6E AX210
Audio ports (Rear)
Realtek ALC897 Codec
Internal connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 1x 4-pin ATX 12V power connector; 1x 6-pin PCIE power connector; 6x SATA 6Gb/s connectors; 3x M.2 slots (M-Key); 1x USB 3.2 Gen 2 10Gbps Type-C port; 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 5x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x Clear CMOS jumper; 1x TPM module connector; 1x TBT connector (supports RTD3); 1x Tuning Controller connector
