1x HDMI port, supports a maximum resolution of 4096x2160 @30Hz; 1x DisplayPort, supports a maximum resolution of 4096x2304 @60Hz
Max minneshastighet
2933 MHz
Övriga specifikationer
USB
6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 ports through the internal USB 3.2 Gen 1 connector); 1x USB 3.2 Gen 1 5Gbps port (1 Type-C internal connector); 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors); 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel
HDMI
1
RAID
0/1/5/10
Socket
1200
DirectX
12
SATAIII
6
M.2 Slot
2
PCI-E x1
2
CrossFire
Y
PCI-E Gen
Gen3
PCI-E x16
2
DIMM Slots
4
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 10 64-bit
DisplayPort
1
Form Factor
ATX
LED Features
1x EZ LED Control switch; 4x EZ Debug LED
TPM (header)
1
BIOS Features
1x 128 Mb flash; UEFI AMI BIOS; ACPI 6.2, SM BIOS 3.2 ∙Multi-language
Expansion Slot
1x PCIe 3.0 x16 slot (From CPU, PCI_E1), supports x16 mode; 1x PCIe 3.0 x16 slot (From PCH, PCI_E3), supports x4 mode 1; 2x PCIe 3.0 x1 slots (From PCH); PCI_E3 will be unavailable when installing M.2 SSD in the M2_2 slot.
I/O Controller
NUVOTON NCT6687 Controller Chip
Memory Channel
Dual
Max Memory (GB)
128
Back panel ports
PS/2 Combo Port; DisplayPort; 1G LAN Port; 2.5G LAN Port; HD Audio Connectors; USB 2.0 Ports; HDMI; USB 3.2 Gen 2x2 20Gbps (Type-C); USB 3.2 Gen 1 5Gbps (Type-A); USB 3.2 Gen 1 5Gbps (Type-A); Optical S/PDIF OUT
Hardware Monitor
CPU/System temperature detection; CPU/System fan speed detection; CPU/System fan speed control
Audio ports (Rear)
5
Internal connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 6x SATA 6Gb/s connectors; 2x M.2 slots (M-Key); 1x USB 3.2 Gen 1 5Gbps Type-C port; 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 6x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 2x 4-pin RGB LED connector; 2x 3-pin RAINBOW LED connectors; 1x TPM module connector; 1x Clear CMOS jumper; 1x TBT connector1; Thunderbolt card need support RTD3
