1x VGA port, supports a maximum resolution of 2048x1536 60Hz, 1920x1200 60Hz; 1x HDMI 1.4 port, supports a maximum resolution of 4K 30Hz 1 2; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
USB
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector); 6x USB 2.0 ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 2.0 connector)
VGA
1
HDMI
1
Socket
LGA 1200 socket
DirectX
12
SATAIII
4
Mounting
6 mounting holes
PCI-E x1
2
PCI-E x16
1
Processor
Please go to www.intel.com for more compatibility information.
DIMM Slots
2
Dimensions
mATX Form Factor; 9.3 x 7.5 in. (23.6 cm x 19.0 cm)
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 10 64-bit
Form Factor
Mirco-ATX
TPM (header)
1
Expansion Slot
1x PCIe x16 slot (From CPU) Support up to PCIe 4.0 for 11th Gen Intel CPU Support up to PCIe 3.0 for 10th Gen Intel CPU; Support up to PCIe 4.0 for 11th Gen Intel CPU; Support up to PCIe 3.0 for 10th Gen Intel CPU; 2x PCIe 3.0 x1 slots (From PCH)
Memory Channel
Dual
Max Memory (GB)
64
Back panel ports
VGA; HDMI; USB 3.2 Gen 1 5Gbps Type-A; Mouse / Keyboard; LAN port; Audio connector; USB 2.0; USB 2.0
Operating System
Support for Windows 10 64-bit
Audio ports (Rear)
Realtek ALC897 Codec
Internal connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 4x SATA 6Gb/s connectors; 1x USB 3.2 Gen 1 5Gbps connector (support additional 2 USB ports); 1x USB 2.0 connector (support additional 2 USB ports); 1x 4-pin CPU fan connector; 1x 4-pin system fan connector; 1x Front panel audio connector; 2x System panel connectors; 1x Serial port connector; 1x Chassis Intrusion connector; 1x Clear CMOS jumper; 1x TPM module connector
